China Customized Wireless Charger FR4 PCB Assembly
China Customized Wireless Charger FR4 PCB Assembly
Specifications
Certification :
ISO, UL, IPC, Reach
MOQ :
1
Payment Terms :
T/T
Supply Ability :
Post-soldering 700,000 points/day
Delivery Time :
5-30 days
Layer :
6 Layer
Material :
FR4
Board Thickness :
2.0mm
Surface Finish :
Immersion Gold
Pin Space :
0.2mm
Application :
Medical
Description


China Customized Wireless Charger FR4 PCB Assembly



♦ What Is Wireless Charger PCBA?


A Wireless Charger PCBA (Printed Circuit Board Assembly) is the fully assembled and functional circuit board inside a wireless charger. It includes:


    • All soldered components (coils, ICs, capacitors, resistors, etc.)
    • Power management
    • Wireless transmission/reception logic
    • Ready for integration into a charger housing






♦ Technical Parameters


PCB Assembly Capability

Item

Normal

Special

SMT

Assembly

PCB(used for SMT)

specification

Length and Width( L* W)

Minimum

L≥3mm, W≥3mm

L＜2mm

Maximum

L≤800mm, W≤460mm

L ＞ 1200mm, W＞500mm

Thickness( T)

Thinnest

0.2mm

T＜0.1mm

Thickest

4 mm

T＞4.5mm

SMT components specification

Outline Dimension

Min size

0201(0.6mm*0.3mm)

01005(0.3mm*0.2mm)

Max size

200 * 125

200 * 125

component thickness

T≤15mm

6.5mm＜T≤15mm

QFP,SOP,SOJ

(multi pins)

Min pin space

0.4mm

0.3mm≤Pitch＜0.4mm

CSP/ BGA

Min ball space

0.5mm

0.3mm≤Pitch＜0.5mm

DIP

Assembly

PCB specification

Length and Width( L* W)

Minimum

L≥50mm, W≥30mm

L＜50mm

Maximum

L≤1200mm, W≤450mm

L≥1200mm, W≥500mm

Thickness( T)

Thinnest

0.8mm

T＜0.8mm

Thickest

3.5mm

T＞2mm





♦ Application Fields


China Customized Wireless Charger FR4 PCB Assembly China Customized Wireless Charger FR4 PCB Assembly China Customized Wireless Charger FR4 PCB Assembly China Customized Wireless Charger FR4 PCB Assembly
PCBA Prototype Industrial Control PCBA Telecom PCBA Medical PCBA
China Customized Wireless Charger FR4 PCB Assembly China Customized Wireless Charger FR4 PCB Assembly China Customized Wireless Charger FR4 PCB Assembly China Customized Wireless Charger FR4 PCB Assembly
Automotive PCBA Consumer Electronic PCBA LED PCBA Security PCBA





♦ Advantages of DQS Team

  1. On-time Delivery:
    • Owned PCBA factories 15,000 ㎡
    • 13 fully automatic SMT lines
    • 4 DIP assembly lines


2. Quality Guaranteed:

    • IATF, ISO, IPC, UL standards
    • Online SPI, AOI, X-Ray Inspection
    • The qualified rate of products reach 99.9%


3. Premium Service:

    • 24H reply your inquiry
    • Perfect after-sales service system
    • From prototype to mass production
