Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm
Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm
Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm
Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm
Specifications
Brand Name :
CESGATE
Model Number :
NA
Certification :
ISO9001/ ISO14001
Place of Origin :
China
MOQ :
1PCS( NO MOQ)
Price :
Negotiable (Depends on your GERBER and BOM)
Payment Terms :
T/T, L/C
Supply Ability :
30,000pcs/month
Delivery Time :
1-30 working days
Packaging Details :
PCB: Vacuum Packing / PCBA: ESD Packing
Product name :
OEM Electronic Components Quick turn PCB Prototype Service Customized Logo
Material :
Stainless Steel, Aluminum, Plastic, Brass, Copper etc
Optional Service :
3 4 5 6 Axis CNC Machining Service
Min. line spacing :
4mil, 0.003", 0.1mm4mil), 0.1mm, 4/4mil(0.1/0.1mm)
Min. line width :
4mil, 0.1mm, 0.1mm/4mi, 0.075mm/0.075mm(3mil/3mil), 3mi
Min. hole size :
0.2mm, 8 mil, 0.10mm, 3mil (0.075mm), 0.004"
MOQ :
Small Orders Accepted
Features :
OEM/Quick Turn
Description

OEM Electronic Components Quick turn PCB Prototype Service Customized Logo

Production Equipments

CESGATE is equipped with central air conditioning, constant temperature and humidity warehouse, air shower room, anti-static treatment, etc. Equipped with new imported Fuji XPF, NXT3, automatic solder paste printing machine, ten temperature zone reflux furnace, wave soldering, AOI/SPI/XRAY/First Article Inspection. CESGATE works well in high-precision, high-complexity PCB Prototype Service, and acts in producing ultra-complex PCB Prototype Service.

Technical Requirement for PCB Prototype Service

  • 1) Professional Surface-mounting and Through-hole soldering Technology
  • 2) Various sizes like 1206, 0805, 0603 components SMT technology
  • 3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
  • 4) PCB service With CE, FCC, Rohs Approval
  • 5) Nitrogen gas reflow soldering technology for SMT.
  • 6) High Standard SMT&Solder Assembly Line
  • 7) High density interconnected board placement technology capacity.


PCB Prototype Service Quality Control

  • AOI: Detect various problems after placement: short circuit, material leakage, polarity, displacement, wrong parts
  • Xray: Open circuit and short circuit detection of BGA, QFN and other devices.
  • Adhesive cardboard: Test whether the SMT placement position is correct, greatly reduce the SMT trial production time and the waste of components, and effectively ensure the quality of SMT.
  • Intelligent first-piece detector: detects wrong materials, missing parts, polarity, orientation, silk screen, etc., mainly used in the detection of first-piece; compared with manual detection, the accuracy is higher and the speed is increased by 50%+.
  • SPI-Automatic 3D Solder Paste Thickness Gauge: Detects various solder paste printing quality problems such as missing printing, less tin, more tin, continuous tin, offset, poor shape, board surface pollution, etc.

PCB Prototype Service Capacities and Technical Specification

NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm

Company Descripiton

Producing a qualified product is crucial to CESGATE and to you. To ensure PCB Prototype Services are compliant we use a number of inspection and Quality assurance procedures. Including Automatic Optical Inspection equipment and CAD software as well as continuous improvements. We are accredited to ISO9001:2015 as well as being a preferred supplier to many of our customers.
With access to global suppliers, and distribution networks we can source parts for your assemblies as needed. Using our own in-house Stock and MRP system which links to our production data we are able to manage Inventory levels, lead times and buffer stocks to meet your deadlines.

Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mmRogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mmRogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mmRogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm

Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mmRogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm

Rogers 4003 PCB Prototype Service Prototype Board 0.2mm 8 Mil 0.10mm

FAQ

Q: IS PRODUCT PICTURES AND LABELS AVAILABLE?
CESGATE: We will offer after you place an order or before shipment.
Q: WHAT IS YOUR TERMS OF PACKING?
CESGATE: Generally, we pack our goods in neutral white boxes and brown cartons.
Q: WHAT IS YOUR MOQ?
CESGATE: MOQ is SPQ normally, while it depends on your specific order. (Sample is available if the buyer can afford the shipping fee.)
Q: DO YOU TEST ALL YOUR GOODS BEFORE DELIVERY?
CESGATE: 1. Our products are all original, and we will test the goods before shipment by professional machines like KEYSIGHT E4991A and KEYSIGHT E4980.
2. If The buyer need Test Report, we can send the product to anthoritative institution such as White horse Laboratories(SZ) Limited,Global Electronics Testing,etc.
