Immersion Gold PCB Prototype Service OSP Solar Light Circuit Board
Immersion Gold PCB Prototype Service OSP Solar Light Circuit Board
Immersion Gold PCB Prototype Service OSP Solar Light Circuit Board
Immersion Gold PCB Prototype Service OSP Solar Light Circuit Board
Specifications
Brand Name :
CESGATE
Model Number :
NA
Certification :
ISO9001/ ISO14001
Place of Origin :
China
MOQ :
1PCS( NO MOQ)
Price :
Negotiable (Depends on your GERBER and BOM)
Payment Terms :
T/T, L/C
Supply Ability :
30,000pcs/month
Delivery Time :
1-30 working days
Packaging Details :
PCB: Vacuum Packing / PCBA: ESD Packing
Product name :
Solar Light Circuit Board Smt Assembly Supplier PCB Prototype Service Epicor Bom
Material :
316L,Aluminum, Brass, Bronze, Copper, stainless steel, Steel A
Optional Service :
3 4 5 6 Axis CNC Machining Service
Min. line spacing :
4mil, 0.003", 0.1mm4mil), 0.1mm, 4/4mil(0.1/0.1mm)
Min. line width :
4mil, 0.1mm, 0.1mm/4mi, 0.075mm/0.075mm(3mil/3mil), 3mi
Min. hole size :
0.2mm, 8 mil, 0.10mm, 3mil (0.075mm), 0.004"
Surface finishing :
HASL, OSP, HASL Lead Free, ENIG, Immersion Gold
Application :
Consumer Electronics, power, automotive, industry, Electronic product
Description

Solar Light Circuit Board Smt Assembly Supplier PCB Prototype Service Epicor Bom

CESGATE Offering

a full range of testing service. Including:
*AOI(Automatic Optical Inspection)
* Function Testing
* In Circuit Testing
* Testing Jig
* Testing Service
* X-Ray for BGA Testing
* Printing Solder Paste Test

PCB prototype service Capacities and Technical Specification

NO. Items Capabilities
1 Layers 2-68L
2 Maximum machining size 600mm*1200mm
3 Board thickness 0.2mm-6.5mm
4 Copper thickness 0.5oz-28oz
5 Min trace/space 2.0mil/2.0mil
6 Minimum finished aperture 0. 10mm
7 Maximum thickness to diameter ratio 15:1
8 Via treatment Via, blind&buried via, via in pad, Copper in via …
9 Surface finish/treatment HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10 Base Material FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350,
Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11 Solder mask color Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12 Testing Service AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13 Profiling Punching Routing,V-CUT,Beveling
14 Bow&twist ≤0.5%
15 HDI type 1+n+1,2+n+2,3+n+3
16 Min mechanical aperture 0.1mm
17 Min laser aperture 0.075mm

PCBA Capabilities

Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO SMT and DIP lines
Lead Time Prototype : 15 work days. Mass order : 20~25 work days
Testing on products Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed PCB : Gerber files(CAM, PCB, PCBDOC)
Components : Bill of Materials(BOM list)
Assembly : Pick-N-Place file
PCB Panel Size Min size : 0.25*0.25 inches(6*6mm)
Max size : 1200*600mm
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave
Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

Briefly Introduce Our Strength

1. The production of circuit board equipment is very important. Before looking for a supplier, most users will know about a manufacturer with a good reputation in the industry. The production equipment of a good PCB circuit board factory will never get worse, and customers can judge the production strength of the circuit board manufacturer by analyzing the production equipment and scale of the circuit board manufacturer.
2. When making PCB double-sided, every process is important. Any PCB circuit board manufacturer will have professional inspectors. Only 100% qualified products will be shipped to customers. For prototype PCB service manufacturers with very high product requirements that pass strict inspection procedures, the one-time pass rate can reach more than 98%.
3.Before ordering circuit board prototype PCB service production, you should know the qualification certificate of the PCB circuit board manufacturer. Don't underestimate these certificates. We can use it to know the establishment date of the manufacturer. A qualified PCB factory can survive. There must be some truth to it.

Application

From smartphones to kitchen appliances, electronics play an important role in our daily work. At the heart of every electronic product is the Printed Circuit Board (PCB). It is the foundation of most electronics today. These components have a large number of configurations that allow them to provide various functions. With the expansion and development of electronic products in various industries, PCB applications are also constantly developing. Today, the use of PCBs covers almost every industry and is constantly evolving into new industries and applications. prototype PCB services are the main functional center of most electronic products in the modern world. Circuit boards connect components to each other through a series of related circuits.

Immersion Gold PCB Prototype Service OSP Solar Light Circuit BoardImmersion Gold PCB Prototype Service OSP Solar Light Circuit BoardImmersion Gold PCB Prototype Service OSP Solar Light Circuit BoardImmersion Gold PCB Prototype Service OSP Solar Light Circuit Board

Immersion Gold PCB Prototype Service OSP Solar Light Circuit BoardImmersion Gold PCB Prototype Service OSP Solar Light Circuit Board

Immersion Gold PCB Prototype Service OSP Solar Light Circuit Board

FAQ

Q: Which express companies do you cooperate with?
CESGATE: We cooperate with express companies, including DHL, FedEX, UPS, TNT and EMS. And we also have our own freight forwarders, with lower shipping fees.
Q: The Wire Bonding process is required when the circuit board is printed. What should I pay attention to when making the circuit board?
CESGATE: When making circuit boards, the surface treatment options are mostly "nickel palladium gold ENEPIG" or "chemical gold ENIG". If the Al aluminum wire is used, the gold thickness is recommended to be 3μ”～5μ”, but if the Au gold wire is used, the gold thickness should preferably be more than 5μ”.
Q: MOQ?
CESGATE: There is no MOQ in POE. We are able to flexibly handle small and large batches.
Q: Can you give us a preferential discount?
CESGATE: Of course, we will offer a preferential discount for your large orders and confirm the order quickly.
Q: Why choose us?
CESGATE: Professional and experienced R&D team. Advanced production equipment, scientific and reasonable process flow.
Reliable and strict quality control system. We test all our products before shipment to make sure everything is in perfect condition.
Q: What modes of transport are there?
CESGATE: Usually includes express, air shipment, rail shipment and sea shipment.
