Fast Turn HDI PCB Prototyping with 0.04mm Line Width/Space and 0.3mm BGA Pitch for Compact Designs
Fast Turn HDI PCB Prototyping with 0.04mm Line Width/Space and 0.3mm BGA Pitch for Compact Designs
Fast Turn HDI PCB Prototyping with 0.04mm Line Width/Space and 0.3mm BGA Pitch for Compact Designs
Fast Turn HDI PCB Prototyping with 0.04mm Line Width/Space and 0.3mm BGA Pitch for Compact Designs
Specifications
Brand Name :
Kingtech
Place of Origin :
China
Certification :
GJB9001C, ISO13485, ISO9001, IS045001,IATF16949, UL, ISO14001, AS9100D, QC080000
MOQ :
1pcs
Price :
By quote
Packaging Details :
Vacuum packing
Delivery Time :
2-7days
Payment Terms :
By quote
Supply Ability :
500000 SQM per month
Min. Line widthe/space :
0.04mm/ 0.04mm
Warpage :
≤0.4%
BGA Pitch :
0.3mm
Misalignment of layers :
+/- 0.06
Blind Hole Aspect Ratio :
1:1
Vias Aspect Ratio :
16:1
Min. Mechanical Drill Hole size :
0.1mm
Impedance Control :
±8%
Description
Product Overview
This ODM HDI PCB is engineered for high-density, multilayer electronic applications requiring stable thermal performance, fine-pitch routing, and reliable signal integrity. Utilizing high-Tg laminate materials and controlled HDI processes, the board maintains mechanical and electrical stability under continuous thermal stress. Ideal for industrial control systems, communication equipment, and advanced embedded systems. We support complete production from prototype to volume manufacturing, ensuring design consistency throughout all stages.

Key Technical Capabilities


  • Product Name: HDI
  • Min. Line Widthe/Space: 0.04mm/ 0.04mm
  • Warpage: ≤0.4%
  • Impedance Control: ±8%
  • Min. Laser Drill Hole Size: 0.07mm
  • Copper Thickness: 1/3-8
  • High Density Interconnect (HDI) Printed Circuit Boards



Parameter Value
Warpage ≤0.4%
Impedance Control ±8%
Max. Board size 540*620
Misalignment of layers +/- 0.06
Board Thickness 0.2-3.2mm
Min. Core Thickness 0.05
Min. Mechanical Drill Hole size 0.1mm
Vias Aspect Ratio 16:1
BGA Pitch 0.3mm
Min. Line widthe/space 0.04mm/ 0.04mm

Why Choose Our OEM PCB Boards?
  • Direct PCB Manufacturer – no trading risk
  • Fast Turnaround for prototypes and NPI projects
  • Strict Quality Control (ISO / IATF / AS standards)
  • Engineering Support for DFM & stack-up
  • Stable Mass Production Capability
  • Export-oriented factory serving EU & US markets

Fast Turn HDI PCB Prototyping with 0.04mm Line Width/Space and 0.3mm BGA Pitch for Compact Designs

Fast Turn HDI PCB Prototyping with 0.04mm Line Width/Space and 0.3mm BGA Pitch for Compact Designs

pplication Areas


  • This fast turn HDI PCB solution is widely used in:
  • Compact consumer electronics
  • IoT & smart hardware
  • Embedded control modules
  • Communication and terminal devices


These applications typically require small form factor designs and fast iteration cycles.
