3W UV Laser Unit Touch Screen Laser Marking Machine With High-Speed Digital Galvanometer
3W UV Laser Unit Touch Screen Laser Marking Machine With High-Speed Digital Galvanometer
3W UV Laser Unit Touch Screen Laser Marking Machine With High-Speed Digital Galvanometer
3W UV Laser Unit Touch Screen Laser Marking Machine With High-Speed Digital Galvanometer
Specifications
Brand Name :
HSTECH
Model Number :
HS-UV3W
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
7~9 work days
Packaging Details :
Wooden package
Product Name :
UV Laser Marking Machine
Warranty :
1 Year
Control :
Touch Screen
Material :
Aluminum Alloy
Application :
Electronic Assembly
Total Power :
2600W
Power Supply :
AC220V
Weight :
30KG
Description

3W UV Laser Unit Touch Screen Laser Marking Machine With High-Speed Digital Galvanometer

Introduction

UV Laser Marking Machine is a specialized industrial device that utilizes ultraviolet (UV) laser technology for marking, engraving, or coding various materials.

​Specification

Model HS-UV3W
Output power 3W
Laser type 3W UV laser unit
Marking area 150*150mm(Optional)
Laser point diameter <0.01mm
Laser output power 0~100% adjustable
Working frequency range 5~100KHz
Power stability <±1%rms
Laser wave length 355nm
Marking type Static marking/Dynamic marking
Marking speed ≤7000m/s
Min character 0.15mm
Repeat accuracy ±0.003mm
Laser unit Chinese brand/Overseas brand(optional)
Cooling type Air cooling
Power supply AC220V,60Hz,15A
Software Professional SW
Laser lifespan 20000Hrs
Machine size 900mm*680mm*1500
Machine weight 120kg

Features

1, 3,5W UV laser output power.

2, Little power consumption, energy consumption is 500 watts.

3. Using high-speed digital galvanometer, it is 2-4 times faster than normal models.

4. High marking accuracy at ±0.003MM, and the marking content coordinates can be fine-tuned.

5. The equipment has stable performance, high positioning accuracy, and can work continuously for 24 hours.

6. The equipment marking software can support AI, PLT, CAD (DXF), CDR, and other formats of vector graphics, and can be imported indirectly or directly.

7. Simple and the marking software can still be upgraded for free after guarantee.

8. Mainly used in many industries such as hardware, communication, electronics, auto parts, plastics, handicrafts, etc.

Applications


Electronics Industry:
Used for marking components, circuit boards, and labels, ensuring traceability and compliance with regulatory standards.
Medical Devices:
Ideal for marking surgical instruments, implants, and packaging, where precision and cleanliness are critical.
Packaging:
Suitable for printing barcodes, QR codes, and product information on various packaging materials.
Automotive Industry:
Employed for marking identification numbers, logos, and other information on automotive parts.
Jewelry and Crafts:
Used for engraving intricate designs or logos on jewelry pieces and other artistic items.
