Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
YUSH
Model Number :
YS--S330
MOQ :
1 set
Price :
$7,800 / set
Weight :
70 KG
Working Area :
300*300*60 mm
Working Humidity :
20~90% no condensation
Dimensions :
485*505*610 mm
Voltage :
250W
Glue Pump Viscosity :
almost all viscosity
Dispensing Head :
one or more on request
Power :
220/110 V
Max Speed :
500mm/sec
Min Dispensing Quantity :
0.001ml
Resolution :
0.01mm
Repeatability :
+/-0.01mm
Size :
460*450*480 mm
Core Components :
Motor
Axes :
3 or 4
Description
Industrial Robotic Glue Dispenser
CNC Glue Dispensing Robot Made in China
Compatible Adhesive Types
Suitable for silicone glue, UV glue, AB glue, epoxy (black glue), COB black glue, white glue, EMI conductive glue, epoxy resin, instant glue, silver glue, red glue, paste, thermal grease, welding control paste, transparent paint, and more.
Application Capabilities
Can perform dot dispensing, draw lines, squares, circles, and all kinds of irregular graphics on product surfaces, exterior walls, vertical planes, and within product gaps.
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Technical Specifications
Power 220/110 V
Voltage 250W
Working Area (X*Y*Z) 300*300*60 mm (Customizable)
Speed Max. 500mm/sec
Dispensing Quantity Min. 0.001ml
Resolution 0.01mm
Repeatability +/-0.01mm
Size (L*W*H) 460*450*480 mm
Weight 70KG
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Key Features
  • Full automatic robot with 3 or 4 axes
  • Dispensing path can be set in the robot or imported from external computer
  • Easy operation with amendable holder and programs
  • Can store multiple independent running programs
  • High precision with well-controlled glue application
  • Can configure multiple dispensing heads
  • Wide dispensing area capable of setting several products
  • Working table can be customized on request
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
Industry Applications
  • Electro-acoustic industry: speakers, buzzers, audio, headphones
  • Inductance industries: small transformers, SMD transformers, relays, small coil motors
  • Communications industry: cell phone keyboard, mobile phone shells, radio, telephone, fax
  • Computers, digital products, digital cameras, MP3, MP4, electronic toys
  • Switches, connectors, wire, plug cable
  • Electronics: electronic components, integrated circuits, circuit board solder paste, electronic parts, LCD liquid crystal screens
  • Optics: optical lenses, optical heads
  • Mechanical hardware, battery boxes, trademarks, steam machinery spare parts
  • LED industries
Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China Industrial Robotic Glue Dispenser . Cnc Glue Dispensing Robot Made in China
