Specifications
Place of Origin :
Jiangsu, China
Brand Name :
YUSH
Certification :
ce
MOQ :
1 set
Price :
$28,000 / set
Weight :
3500 kg
Power :
5 kW
Voltage :
220V, 110V
Model :
YSVC-650
Laser wavelength :
355nm
Laser power :
10W
Maximum format :
610mm X 500mm
Operating speed :
50m/min
Positioning accuracy :
±3um
Repeatability :
±1um
System precision :
±20um
Scanning range :
50mm X 50mm
Cutting thickness :
<1mm
Dimensions :
1818mm X 2317mm X 1550mm
Humidity range :
<60% RH non-condensing
Description
YSVC-650 Industrial-Grade CNC Laser Cutting Machine
The YSVC-650 metal tube laser cutting machine from YUSH Technology is engineered for precision fabrication of flexible printed circuits (FPC) and metal tube cutting applications. As a leading brand in PCB industry equipment, YUSH Technology delivers reliable performance for demanding manufacturing environments.
Primary Applications
This FPC ultraviolet laser cutting machine is specifically designed for precision cutting of flexible circuit boards, CVL, RF components, and thin plywood materials. It enables mold-free processing without protective plate fixation, making it ideal for organic coating applications and complex shape cutting.
Industrial-Grade CNC Laser Cutting Machine- Brand New for Metal Tube Cutting & FPC Precision Fabrication
Key Features & Advantages
  • Proprietary control software with intuitive interface and comprehensive functionality
  • Capable of processing any graphics with synchronized hierarchical completion
  • Optimized optical system ensures high beam quality and reduced focused spot size
  • High-performance UV laser with 355nm wavelength delivers superior peak power
  • Minimal thermal effect with precision cutting, smooth edges, and steep sidewalls
  • Vacuum sample fixation eliminates need for mold protection plates
  • Versatile substrate compatibility including silicon, ceramic, and glass materials
  • Advanced automation with automatic correction, positioning, and thickness compensation
Industrial-Grade CNC Laser Cutting Machine- Brand New for Metal Tube Cutting & FPC Precision Fabrication
Technical Specifications
Laser System
Solid-state UV laser source | Wavelength: 355nm | Laser Power: 10W
Processing Capabilities
Maximum processing format: 610mm × 500mm (24" × 18") | XY platform speed: 50m/min | Cutting thickness: <1mm
Precision Metrics
Positioning accuracy: ±3μm | Repeatability: ±1μm | System precision: ±20μm | Galvanometer scanning range: 50mm × 50mm
Power Requirements
AC220V 50Hz / 2.2KW or three-phase 380V 50Hz / 5.5KW
Environmental Specifications
Welcome home requirements: 516m³/h | Dimensions: 1818mm × 2317mm × 1550mm | Weight: 3500Kg | Ambient temperature: 20℃ ±2℃ | Humidity: <60% RH non-condensing
Control System
Industry-specific control equipment with flexible processing software | Dedicated motion control card and IPC control mode | 17" monitor | 300G+ hard drive | Supports standard G-code, Gerber data, and CAD formats
Industrial-Grade CNC Laser Cutting Machine- Brand New for Metal Tube Cutting & FPC Precision Fabrication
Quick Reference Specifications
Parameter Specification
Maximum Board Length 610 × 500mm
Package Size 1818mm × 2317mm × 1550mm
Thickness 1mm
Power Supply AC220V 50Hz / 2.2KW; three-phase 380V 50Hz / 5.5KW
Working Air Pressure 516m³/h
Weight 3500kg
Scope of Application All V-CUT SMD PCB FPC board
Industrial-Grade CNC Laser Cutting Machine- Brand New for Metal Tube Cutting & FPC Precision Fabrication
The YSVC-650 represents the pinnacle of precision laser cutting technology, combining advanced UV laser capabilities with robust industrial construction for reliable performance in demanding manufacturing applications.
