Specifications
Place of Origin :
Guangdong, China
Brand Name :
YUSH
MOQ :
1 set
Price :
$17,000 / set
Weight :
300 kg
Power :
150W
Voltage :
220V, 110V
Model :
YSV-4A
Blade size :
200*43.5*6mm
Working pressure :
0.5~0.8Mpa
Cutting width :
Max 200mm
V-cut thickness :
One third of the plate thickness
Blades material :
Imported high quality high speed steel, titanium coated
Cutting boards :
Fiberglass board, FR4 board, aluminum substrate, copper substrate
Feeding structure :
Precision pneumatic module
Positioning :
V cut line positioning, screen displays feed data
Micro stress :
About 200
Cutting stroke :
Below 2mm
Description
High-Precision Automatic COB Board Processing Machine
Professional COB PCB Assembly & Handling Equipment designed for efficient and precise board processing operations.
High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment
Key Features
  • Microcomputer-controlled automatic board feeding system specifically developed for COB light source PCB cutting
  • Versatile cutting capability for various COB substrates, bulb LED aluminum substrates, and ceramic plates
  • 5-6 times faster processing efficiency compared to traditional board machines
  • Minimal component stress (approximately 200) during cutting to prevent tin cracking and protect precision parts
  • Gas hybrid design with double straight knife slitting for precision PCB board division
  • Scythe work mechanism suitable for various thickness MCPCB with cutting stroke below 2mm
  • Anti-dwelling structure design ensuring operational safety
High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment
Technical Specifications
Model YSV-4A
Weight 230KG
Blade Size 200×43.5×6mm (Straight knife)
Voltage 220V
Working Pressure 0.5~0.8Mpa
Cutting Width Max 200mm
V-cut Thickness One third of plate thickness
Blades Material Imported high-quality high-speed steel, titanium coated
Power 150W
Cutting Boards Fiberglass board, FR4 board, aluminum substrate, copper substrate
Feeding Structure Precision pneumatic module
Positioning V-cut line positioning with screen display of feed data
High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment
Manufacturer Information
YUSH Electronic Technology Co., Ltd was founded in 2004 and is located in Jiangsu, China's world manufacturing hub. The company specializes in professional PCB separator and PCB depaneling electronic equipment machinery. YUSH maintains advanced production and processing equipment with an experienced development and manufacturing team, half of whom have over 10 years of experience in the electronic equipment industry. Since 2004, the company has focused on developing and manufacturing PCB separators and depaneling machines, emphasizing product quality, safety, and innovation. YUSH produces high-quality, stable performance, cost-effective products that improve production yields, increase productivity, and enhance customer market competitiveness. The product line includes various PCB separating types with manual, motor-driven, pneumatic-driven, mold punching, and milling cutter router options. With good quality and reasonable pricing, YUSH serves customers worldwide and has become one of China's largest PCB separator production bases.
