Specifications
Place of Origin :
Guangdong, China
Brand Name :
YUSH
MOQ :
1 set
Price :
$10,000 / set
Voltage :
220 V/ 110V
Dimension :
720mm(L)*300mm(W)*440(H)
Weight :
165kg
Power :
1 kW
Cutting thickness :
0.3-3.5mm
Max length :
330mm
Working air pressure :
0.5-0.7Mpa
Size :
620*230*400mm
Cutting stroke :
below 2mm
Internal stress :
below 180uE
V groove edge :
0.3mm
Parts height :
60mm
Segmentation rate :
1 separation per second
Blade warranty :
200000 cuts
Air compressor :
4-5KG
Description
YSVC-2 FR4 Board PCB V-Cut Machine & V-Groove Separator
Automatic PCB depaneling machine specifically designed for FR4 boards, featuring minimal cutting stress to protect components on the circuit board.
YSVC-2 FR4 Board PCB V-Cut Machine & V-Groove Separator for SMT Workshop Processing
Product Introduction
Utilizing advanced gas-electric lightweight design with built-in SERISOR technology, this machine completes shear-stress-free board cutting in a single operation. Particularly suitable for cutting precision SMD components and thin sheets, it eliminates bow waves and micro-cracks common with circular knife cutting methods. The wedge tool enables linear board cutting while minimizing shear stress, protecting sensitive SMD components including capacitors, and reducing potential quality risks. With a cutting stroke below 1mm, it ensures operational safety. The cutting tool is precision-ground from high-speed steel and can be repeatedly sharpened, also suitable for sheet metal operations without V-CUT boards.
YSVC-2 FR4 Board PCB V-Cut Machine & V-Groove Separator for SMT Workshop Processing
Key Features
  • Double straight knife cutting system, ideal for separating precise SMD sheets and aluminum boards
  • Guillotine-type cutting suitable for various PCB thicknesses with cutting stroke below 2mm for enhanced safety
  • Internal stress during cutting reduced to below 180μE to prevent splitting and protect precision components
  • Capable of cutting boards with width between V-groove edge and components of 0.3mm and height of 60mm
  • Cutting tools can be freely re-sharpened after wear
YSVC-2 FR4 Board PCB V-Cut Machine & V-Groove Separator for SMT Workshop Processing
Technical Specifications
Maximum Board Length 300mm / 400mm
Package Size 720mm(L) × 300mm(W) × 440mm(H)
Thickness Range 0.50 - 3.5mm
Power Supply 220VAC / 110V
Working Air Pressure 0.4 - 0.6Mpa
Weight 189 kg
Application Scope All V-CUT SMD PCB boards
YSVC-2 FR4 Board PCB V-Cut Machine & V-Groove Separator for SMT Workshop Processing
Performance Characteristics
  • Segmentation rate of 1 separation per second controlled by pedal pneumatic switch
  • Passive start cutting knife group for safe grasping of cutting line and position
  • Minimal cutting stress prevents cracking phenomena
  • Non-roller cutting system eliminates dust, motor drive, and carbon pollution
  • Non-friction cutting method leaves no residual metal
  • Blade warranty: 200,000 cycles with no electrical power supply requirements
  • Proprietary cutting tool design eliminates import dependencies
  • Operates with 4-5kg air compressor for flexible placement without specific cutting site requirements
  • Easy maintenance through oil wiping to prevent rust
