Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
Specifications
Place of Origin :
JiangSu
Brand Name :
YuSH
Certification :
CE, RUV Rheinland (China), GMC(GlobalMarket),ISO9001-2000
Model Number :
YSPE
MOQ :
1
Price :
1000
Packaging Details :
Plywooden case
Delivery Time :
3 days
Payment Terms :
T/T ,Paypal ,West Union ,L/C ,D/P .
Supply Ability :
300 sets/ month
Description

Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm

PCB punching tool:


1, Apply to cut Rigid pcb,Flexible pcb(FPC),Rigid-Flexible pcb
2, Use punching mould to cut with high efficiency
3. Can replace multiple mold for production and mold changing easily
4. The operation is simple and safe


PCB punching tool specifications:

Model YSPE-10T
Punch Contribute (T) 3 (can custom made up to 30T)
Working area (mm) 330*220 (can custom made)
Voltage(V) 110/220
Working air pressure(Mpa) 0.5-0.7
PCB punching tool size (mm) 730*810*1700
PCB punching tool weight (kg) 530














Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm

PCB punching tool features:


1. Machine has strong structure and moves easily with 4 Casters.


2. can replace a variety of mold, and mold changing easily.


3. the lower mold automatic in and out, easy to pick and place products, finished products can fall into the drawer.


4. make internal stress generated by PCB cutting to minimize and avoid tin stress cracking.


5. punching cutting semi-finished PCB with high efficiency.


6. mould and die can be made according to customer's request.

Punching Mould PCB Depaneling Machine High Efficiency 330 X 220mm
