E40 E14 Bulb Cap Crimping Punching Machine With 4 6 8 10PIN Needle
E40 E14 Bulb Cap Crimping Punching Machine With 4 6 8 10PIN Needle
Specifications
Brand Name :
YES
Model Number :
YESC12
Certification :
CE ISO
Place of Origin :
China
MOQ :
one set
Payment Terms :
T/T, L/C
Supply Ability :
300 sets per month
Delivery Time :
1-3 days after payment confirmed
Packaging Details :
each set be packed in plywood case
Air pressure: :
just a little 0.5-0.6Mpa
Voltage: :
Available for 220V and 110V
Punching needles/holes: :
12 needles /12 holes
warranty :
two years
certificate :
CE ISO
lamp base dimension: :
E17,B22,E27,E40,E10,E11 etc.
Description

E40 E14 Bulb Cap Crimping Punching Machine With 4 6 8 10PIN Needle

lamp cap hole punching machine for E27 lamp base ,12 needles

Specifications:

This machine with automatic testing function ,while punching the lamp cap ,the lamp will flash light if the bulb is workable ,can check the effect of punching and whether the lamp is workable or not .

1.Use high quality cylinders ,one cylinder control one needle ,the depth of punching needle can be adjustable .
2.Adopt High quality ,high speed ,harden needles ,hardness>=60%.
3.With function of Automatic counting the number of punching lamps ,can calculate how many pieces of lamps you have punching and display automatically .
4. 0.3-1 seconds punching a lamp cap .
5. 3-4mm distance electromagnetic induction then punching ,can be adjusted.
6.With automatic and semi-atomatic switch (foot operation) ,you can choose the way you want .
7. Two conjoined air filter processor inside to dry the air .
8.Dimensions :L750*W550*H760 mm;

9.Net Weight: about 39 kgs .
10.Can be available for 220V, 110V .
11.One machine for one lamp base , for example ,E27 lamp cap punching machine just workable for E27 lamp base , we can make machines for othe lamp base like :E12,E12S,E14,E14S,E17,E27,B22,E26,E39,E40 ....make by your requirements .

Specifications:

1.Adopted high quality cylinders ,one cylinder control one needle ,the depth of punching needle can be adjustable( total 12 needles ) .

2.needle Adopt High quality ,high speed ,harden needles ,hardness>=60%.

3. Number record function :

With function of Automatic counting the number of punching lamps .

4. Working Speed: 0.3-1 second punching a lamp cap .

5. 3-4mm distance electromagnetic induction then punching (automatic operation mode)

6.optional control method :

With automatic and semi-automatic switch

7. Two conjoined air filter processor inside to dry the air .

8.Dimensions :L400*W450*H200 mm

9.Net Weight: small one about 30 kgs ,big one about 90 KG

10.voltage : 220V /50 HZ

Detailed pictures

E40 E14 Bulb Cap Crimping Punching Machine With 4 6 8 10PIN Needle

E40 E14 Bulb Cap Crimping Punching Machine With 4 6 8 10PIN Needle

E40 E14 Bulb Cap Crimping Punching Machine With 4 6 8 10PIN Needle

led bulb cap hole punching machine

1. This bulb cap hole punching machine , connect the bulb head with the aluminum part .

2, usually 12 needle

3. 1 second can finish a bulb cap

4, automatic and semi-automatic optional

Shipping & Packagings

1.Packing: Plywood case neutral packing , or according to your requirement to design your packing
