94v0 Aluminum PCB with 1-3oz Copper Thickness and 0.1-3.0mm Board Thickness for LED PCB and FR4 PCBA
94v0 Aluminum PCB with 1-3oz Copper Thickness and 0.1-3.0mm Board Thickness for LED PCB and FR4 PCBA
Specifications
Model Number :
HS pcb manufacturer
Place of Origin :
Guangdong, China
Brand Name :
HS
MOQ :
2
Price :
$3
Base Material :
94v0 Aluminum PCB
Copper Thickness :
1-3oz
Board Thickness :
0.1-3.0mm
Min Hole Size :
0.3mm
Min Line Width :
0.2mm
Min Line Spacing :
0.2mm
Surface Finishing :
HASL OSP ENIG
Solder Mask :
Green Blue Red Black White
Number of Layers :
1-12 layers
Finished Thickness :
0.1mm-4.0mm
Board Thickness Tolerance :
±10%
Copper Plating Hole :
18-40 um
Impedance Control :
±10%
Warp & Twist :
0.70%
Min Trace Width :
0.075mm
Description

Shenzhen Aluminum circuit board pcb factory PCB supplier

We can do for you:

♦ 1—12 layer FR4 PCB,1 layer Aluminum PCB,1-4 layer Flexible PCB.

♦ 1—3oz copper thickness.

♦ 0.2mm hole size.

♦ 0.1mm track width/space.

♦ SMT PCBA service.

94v0 Aluminum PCB with 1-3oz Copper Thickness and 0.1-3.0mm Board Thickness for LED PCB and FR4 PCBA

FAQ:

Q:1.Can i have a sample to test?

A:Yes,we can send you samples to test.

Q:2.What specifications do you need for PCB quotation?

A:We need your PCB Gerber file,board thickness,copper thickness,surface finishing and quantity to quote you.

Q:3.What is the lead time?

A:Samples need 3-5days,mass production needs 7-10days,also according to the order volume.

Q:4.Do you have MOQ limit?

A:Even 1 pcs,we care.

Q:5.Can you offer the best price for us?

A:Yes,we are specialized PCB manufacturer directly,we can offer lower price than any trading company.

Q:6.How do you ship the goods and how long does it take arrival?

A:We usually ship by DHL,UPS,FedEx and TNT.It takes 3-5days to arrive.

Q:7.What are the payment terms?

A:You can pay us with Paypal,Western Union and T/T Bank.

Q:8.Can we visit your factory?

A:Yes,welcome to visit our factory anytime,and we will lead you to visit our factory and our production line.

Manufacturing Capability:

item

Manufacture Capability

Material

FR-4/HiTg FR-4/Lead free Materials /CEM-3, Aluminium, Metal based

Layer No.

1-12

Finished board thickness

0.1 mm-4.0mm’(8 mil-150 mil)

Board Thickness Tolerance

±10%

Cooper thickness

0.5 OZ-3OZ (18 um-385 um)

Copper Plating Hole

18-40 um

Impedance Control

±10%

Warp&Twist

0.70%

Peelable

0.012"(0.3mm)-0.02’(0.5mm)

Images

Min Trace Width (a)

0.075mm (3mil)

Min Space Width (b)

0.1mm (4 mil)

Min Annular Ring

0.1mm (4 mil)

SMD Pitch (a)

0.2 mm(8 mil)

BGA Pitch (b)

0.2 mm (8 mil)

Solder Mask

Min Solder Mask Dam (a)

0.0635 mm (2.5mil)

Solder mask Clearance (b)

0.1mm (4 mil)

Min SMT Pad spacing (c)

0.1mm (4 mil)

Solder Mask Thickness

0.0007"(0.018mm)

Holes

Min Hole size (CNC)

0.2 mm (8 mil)

Min Punch Hole Size

0.9 mm (35 mil)

Hole Size Tol (+/-)

PTH:±0.075mm;NPTH: ±0.05mm

Hole Position Tol

±0.075mm

Plating

HASL

2.5um

Lead free HASL

2.5um

Immersion Gold

Nickel 3-7um Au:1-5u''

OSP

0.2-0.5um

Outline

Panel Outline Tol (+/-)

CNC: ±0.125mm, Punching: ±0.15mm

Beveling

30°45°

Gold Finger angle

15° 30° 45° 60°

Certificate

ROHS, ISO9001:2008, SGS, UL certificate
