Integrated Sewing Unit for Programmed Sleeve Setting FX-81018GL
Integrated Sewing Unit for Programmed Sleeve Setting FX-81018GL
Specifications
Place of Origin :
CHINA
Brand Name :
FOXSEW
Model Number :
FX-81018GL
Description

Integrated Sewing Unit for Programmed Sleeve Setting FX-81018GL

Share on facebookShare on twitterShare on emailShare on printShare on gmailShare on stumbleuponShare on favoritesShare on bloggerShare on tumblrMore Sharing Services0

  • Product Name:Integrated Sewing Unit for Programmed Sleeve Setting
  • Model NO.:FX-81018GL
  • Origin:Zhejiang,China
  • Brand Name:FOXSEW

Contact Now

Add to Basket

  • Product Details: Integrated Sewing Unit for Programmed Sleeve Setting

Features:
1. Up to 50 gathering styles to fulfill different fullness requirement for various sleeve style, size and material.
Fullness distribution total 100 style for right and left sleeve can be individually programmed and stored.
2. Each sleeve seam can be divided to 12 sections.
3. Stored programmers can be divided out easily simply by inputting the pertinent code number.
4. Extra fullness up to 10-20% can added as when required by the operator.
5. Perfect system due to automatic mirroring grading and repairing.
6. Easy and simple input system, by touch screen.
7. Automatic needle positioning, and thread trimmer.
8. Servo electronic motor.

Specifications:

Max sewing speed

2.000 r. p. m

stitch system

301

Max, stitch length

4mm(bottom)/8mm(top)

Max. fullness per stitch

8mm

Max thickness of material

4mm

needle system

134R

Power supply

single phase 220v/50-60HZ(Other voltage available upon request)

Pneumatic

6KG/cm

  • Product Images: Integrated Sewing Unit for Programmed Sleeve Setting
