1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector
1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector
1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector
1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector
Specifications
RL :
>55dB
IL :
13.5 dB
Cable length :
1.5m
Brand Name :
KCO, Kocent Optec Limited
Model Number :
PLC-RM-1x16-SCA
Certification :
ISO9001, RoHS
Place of Origin :
Guangdong, China
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
Western Union,T/T,L/C
Supply Ability :
20,000 set/ month
Delivery Time :
5~8 days after get payment
Packaging Details :
Carton box, wooden pallet
Port :
1 to 16
PDL :
0.2dB
Connector :
SC/APC or customized
Description
Fiber optic PLC Splitter, 1U 19 inch rack mount, SC/APC
Rackmount PLC Splitter Descriptions:

Fiber optic PLC (Planar Lightwave Circuit) splitters are Single Mode Splitters with an even split ratio from one input fiber to multiple output fibers.

It is based on planar lightwave circuit technology and provides a low cost light distribution solution with small form factor and high reliability.

We provides a various of 1*N and 2*N PLC splitters, including 1x2 to 1x64 and 2x2 to 2x64 1U Rack Mount type fiber PLC splitters.

They are all with superior optical performance, high stability and high reliability to meet various application requirements.

The 1U Rack Mount type adopts 1U frame, or customize according to actual requirement.

It can be installed in ODF canonically and syncretize with appreance of box/ cabinet body via canonical fiber distribution.

1U Rack Mount Fiber PLC Splitter supports SC, LC, FC & ST connectors for choice.

Applications:
  • Optical Signal Distribution
  • Data Communications
  • LAN and CATV System
  • FTTX Deployment
  • FTTH Network
  • Passive Optical Networks (PON)
  • Outside Plant Equipments
  • DWDM and CWDM systems
Features:
  • Configuration Type: 1x16, SC/APC connector or customized
  • Good channel-to-channel Uniformity
  • High Polarization Extinction Ratio
  • Low Input Polarization Sensitivity, Insertion loss≤13.9dB, PDL≤0.3dB
  • Compact design, Custom and Rugged Packaging Available
  • Operating temperature : -40°C to +85°C
  • Operating bandwidth: 1260~1650nm
  • Meet Telcorida GR-1209/ 1221 Qualified
Rack Mount PLC Splitter Product Pictures:
1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector 1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector 1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector 1*32 1x32 1:32 1U Fiber Optic Rack Mount PLC Splitter With SC/APC connector
Rack Mount PLC Splitter Specifications:
Fiber length 1m or custom length
Connector Type Custom specified
Optical Fiber Type Corning SMF-28e fiber, G657A1 or as customized
Directivity (dB) Min * 55
Return Loss (dB) Min * 55 (50)
Power Handling (mW) 300
Operating Wavelength (nm) 1260 ~ 1650
Operating Temperature(°C) -40~ +85
Storage Temperature(°C) -40 ~ +85
Port Configuration 1x2 1x4 1x8 1x16 1x32 1x64
Insertion Loss(dB) Typical 3.6 7.1 10.2 13.5 16.5 20.5
Insertion Loss (dB) Max 4.0 7.3 10.5 13.7 16.9 21.0
Loss Uniformity (dB) 0.6 0.6 0.8 1.2 1.5 2
PDL(dB) 0.2 0.2 0.2 0.25 0.3 0.35
Wavelength Dependent Loss(dB) 0.3 0.3 0.3 0.5 0.5 0.5
Temp. Dependent Loss (-40~85 ) (dB) 0.4 0.4 0.4 0.5 0.5 0.5
Port Configuration 2X2 2X4 2X8 2X16 2X32 2X64
Insertion Loss(dB) Typical 3.8 7.4 10.8 14.2 17 21
Insertion Loss (dB) Max 4.2 7.8 11.2 14.6 17.5 21.5
Loss Uniformity (dB) 1 1.4 1.5 2 2.5 2.5
PDL (dB) 0.2 0.2 0.4 0.4 0.4 0.5
Wavelength Dependent Loss(dB) 0.8 0.8 0.8 0.8 0.8 1
Temp. Dependent Loss(-40~+85°C) 0.5 0.5 0.5 0.8 0.8 1
Rack Mount PLC Splitter Packing ways:

According to export standard packing.

OEM/ODM service:

Our Rack Mount PLC Splitter OEM and ODM service is always ready!

If you want to show your own brand LOGO on the product cable, product package or rack mount, it is no any problem. Our OEM service is always ready to servise you.

Shipping:
  • By International express: TNT, DHL, UPS, special line express, etc
  • By air: CA, ZH, CZ, AA, AC, BA, etc
  • By sea
