B88269X2320C011 TDK/EPCOS HVC500B-24SE High-Voltage Contactors 24VDC Nom 500A
B88269X2320C011 TDK/EPCOS HVC500B-24SE High-Voltage Contactors 24VDC Nom 500A
B88269X2320C011 TDK/EPCOS HVC500B-24SE High-Voltage Contactors 24VDC Nom 500A
B88269X2320C011 TDK/EPCOS HVC500B-24SE High-Voltage Contactors 24VDC Nom 500A
Specifications
Description :
TDK High-Voltage Contactors 24VDC Nom 500A HVC500B-24SE B88269X2320C11 B88269X2320C011
Stock :
10000
Application :
General
Type :
HVC500B-24SE
Manufacturer :
EPCOS / TDK
Product Category :
Contactors - Electromechanical
Coil Voltage :
24 VDC
Contact Current Rating :
500 A
Switching Voltage :
1 kVDC
Contact Termination :
Screw
Description

The B88269X2320C011 is a high-voltage contactor manufactured by TDK, commonly known under the series HVC25. It is designed for applications requiring reliable high-voltage switching capabilities, such as electric vehicles, energy storage systems, and other industrial equipment.

Key Features:

  1. Nominal Coil Voltage: 24 VDC, making it suitable for automotive and industrial applications.
  2. Maximum Operating Voltage: 1000 VDC, allowing for high-voltage switching.
  3. Continuous Operating Current: 500 A, providing robust current handling for heavy-duty applications.
  4. Coil Type: Dual coil, enhancing operational reliability and efficiency.
  5. Polarity: Unipolar, ensuring straightforward integration into existing systems.
  6. Operating Temperature Range: -40°C to +85°C, suitable for various environmental conditions.
  7. Approval: CE, UL60947-4-1, ensuring compliance with international safety standards.

Physical Characteristics:

  • Height: 92.5 mm
  • Width: 89 mm
  • Depth: 44 mm
  • Weight: 500 g
  • Mounting Style: Chassis mount for stable and secure installation.

Packaging and Availability:

  • Packaging: Typically available in bulk packaging.
  • Factory Pack Quantity: Standard package size of 1 unit.

The B88269X2320C011 is characterized by its robust design, ensuring reliable performance in demanding high-voltage applications. It includes an auxiliary contact and offers secure screw termination for both the coil and contact connections.
