Specifications
Brand Name :
CALB
Certification :
MSDS
Model Number :
09111220
Place of Origin :
China
MOQ :
12 Pieces
Price :
Negotiable
Keywords :
LiFePO4 Prismatic Cell
Application :
Electric Folklifts, OTHER, Golf Carts, Electric Power Systems, Power Tools, Electric Bicycles/Scooters, Toys, Solar Energy Storage Systems, Electric Wheelchairs, BOATS, electric vehicles, Home Appliances, SUBMARINES, Electric Bicycles
Battery Size :
135*29*199mm
Weight :
1.65KG
Nominal Voltage :
3.2 Volt
Nominal Capacity :
68ah
Cycle life :
3000times
Size :
135*29*199mm
Selling Units :
Single item
Single package size  :
3.67X15X25 cm
Single gross weight :
1.800 kg
Origin :
Guangdong, China
Description

3000 Times CALB LiFePO4 Battery 3.2V 68AH Prismatic Pouch Cell

LiFePO4 Prismatic Cell Description:

1. The LiFePO4 prismatic battery has short circuit protection.
2. The LiFePO4 prismatic battery has the function of balancing the battery and ensuring long battery life.
3. LiFePO4 square battery has an LED power display function.

LiFePO4 Prismatic Cell Parameter:

Keywords: LiFePO4 Prismatic Cell Application: Electric Forklifts, OTHER, Golf Carts, Electric Power Systems, Power Tools, Electric Bicycles/Scooters, Toys, Solar Energy Storage Systems, Electric Wheelchairs, BOATS, Electric Vehicles, Home Appliances, SUBMARINES, Electric Bicycles
Battery Size: 135*29*199mm Weight: 1.65KG
Nominal Voltage: 3.2 Volt Nominal Capacity: 68ah
Cycle Life: 3000times Size: 135*29*199mm
Selling Units: Single Item Single Package Size : 3.67X15X25 Cm
Single Gross Weight: 1.800 Kg Origin: Guangdong, China

Nominal Voltage
 3.2V
Nominal Capacity
68Ah
Standard Charge Current 13.6A (0.2C rate)
Max. Charge Current
68A (1C rate)
Charge Cut-off Voltage
3.65V
Standard Constant Discharge current
68A/1C
Max Constant Discharge current 136A/2C
Discharge Cut-off Voltage
2.5V
Inner Resistance
≤ 1mΩ (At 0.2C rate, 2.5V cut-off)
Weight
1.65Kg
Dimensions
Length: 199mm
Width: 135.2mm
Thickness: 29.5mm
Operating Temperature
Charging: 0°C ~ 45°C
Discharging: -20°C ~ 60°C
(The cell surface temperature cannot exceed 70°C)
Storage Temperature/Humidity
Temperature: -10°C ~ +35°C
Humidity:65%±20%RH
(optimal store temperature of 23 ± 5°C for long term storage)
Cycle Life ≥2000 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard)

LiFePO4 Prismatic Cell Factory Introduction:

Shenzhen Paisheng Import & Export Co., Ltd. specializes in the production of various 3.7V and 3.2V lithium-ion batteries, chargers, battery BMS and battery packs, etc. The products are widely used in digital products, laptop computers, electrical and electronic products, lighting equipment, toys, household appliances and emergency equipment. We have more than 10 years of battery manufacturing experience, we can assemble batteries and batteries according to your design and requirements.
