FWD-100W-28S Series 100W DC-DC Power Module with 1500VDC Isolation and Ultra-compact Size for Aviation Applications
FWD-100W-28S Series 100W DC-DC Power Module with 1500VDC Isolation and Ultra-compact Size for Aviation Applications
FWD-100W-28S Series 100W DC-DC Power Module with 1500VDC Isolation and Ultra-compact Size for Aviation Applications
FWD-100W-28S Series 100W DC-DC Power Module with 1500VDC Isolation and Ultra-compact Size for Aviation Applications
Specifications
Brand Name :
Forward
Model Number :
FWD-100W-28S Series
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C,T/T
Supply Ability :
10000/year
Delivery Time :
5-8 work days
Input（VDC） :
16～40V
Size :
35.4 × 25.1 × 12.7mm
Temperature cycle :
-55～ + 125℃ , 10 times
Weight :
31g
Cooling method :
Convection,forced air cooling,conduction
Protection :
Moisture proof,salt spray proof,mold proof
Description
FWD-100W-28S Series 1/16 BRICK POWER SERIES 60W DC-DC POWER MODULE
Key Features
  • High Efficiency: 90.3%
  • Max Output Power: Up to 100W
  • Input/Output Isolation: 1500VDC
  • Ultra-compact size: 35.4 * 25.1 * 12.7 mm
  • High reliability: No internal Aluminum and Tantalum electrolytic capacitors
  • Over current, over voltage and short-circuit protection
  • Applications: Military research, Industrial control, radar, fire control, missile-borne, communication systems
Model Specifications
Model Input (VDC) Output (VDC) Output Current Ripple Vp-p Efficiency Size
WBDC100W-28S3R3 16-40V 3.3V 20A 80mV 88% 35.4*25.1*12.7
WBDC100W-28S05 16-40V 5V 20A 80mV 88% 35.4*25.1*12.7
WBDC100W-28S08 16-40V 8V 125A 100mV 89% 35.4*25.1*12.7
WBDC100W-28S012 16-40V 12V 8.33A 100mV 90.3% 35.4*25.1*12.7
WBDC100W-28S15 16-40V 15V 6.66A 100mV 90% 35.4*25.1*12.7
WBDC100W-28S24 16-40V 24V 4.16A 150mV 90% 35.4*25.1*12.7
WBDC100W-28S28 16-40V 28V 3.57A 150mV 89% 35.4*25.1*12.7
WBDC100W-28S32 16-40V 32V 3.12A 100mV 89% 35.4*25.1*12.7
WBDC100W-28S36 16-40V 36V 2.77A 200mV 89% 35.4*25.1*12.7
Important Notes
All data is tested at +25℃ unless otherwise specified, under rated input/output, full load and pure resistive load.
Contact us for custom voltage output requirements.
Models with "N" postfix indicate negative logic, flange-R configuration.
Suffix plus-M (-55 degree activation) naming rules: N-R-M
Input Parameters
Input Parameter Remark Min Typical Max Unit
Input voltage range 28Vin 16 28 40 VDC
Input surge voltage Transient (1s)

50 VDC
Turn on voltage
14 15 16 VDC
Turn off voltage
13 14 15 VDC
No load input current Output no load 48Vin
110
mA
Input/output filtering π Type Multi-level
Enable logic Positive logic: Power on (Enable pin open), Power off (Enable pin shorted)
Negative logic: Power off (Enable pin open), Power on (Enable pin shorted)

General Specifications
General Specification Remark Min Typical Max Unit
Input/output isolation voltage
1500

VDC
Input/housing isolation voltage
1500

VDC
Output/housing isolation voltage
500

VDC
Insulation resistance DC500V 100

MΩ
Switching frequency
200 320 4000 kHz
Working temperature
-40
100 ℃
Storage temperature
-55
125 ℃
Protection Moisture proof, salt spray proof, mold proof

Size
35.4 * 25.1 * 12.7 mm
Cooling method Convection, forced air cooling, conduction

Weight
31 g
Selection Testing Standards
Test Project Method Test Condition Industrial Grade Military Grade
Internal visual inspection GJB548B, 2017.1
100% 100%
High temperature storage GJB150.3A +125℃, 48h
100%
Low temperature storage GJB150.3A -55℃, 48h
100%
Temperature cycle GJB548B, 1010.1 -55～+125℃, 10 times
100%
Intermediate voltage testing - Tc = +25℃
100%
Burn-in
Tc = +85℃, 48h Random check 100%
Final electrical test Product specification -40℃, +25℃, +85℃ (Tc) 100% 100%
External visual inspection GJB548B, 2009.1
100% 100%
Physical Dimensions
Size: 33.2mm (length) * 22.8mm (width) * 9.1mm (height)
FWD-100W-28S Series 100W DC-DC Power Module with 1500VDC Isolation and Ultra-compact Size for Aviation Applications
Pin Configuration
Pin Symbol Function
1 Vi- Input negative
2 EN Control end
3 Vi+ Input positive
4 Vo+ Output positive
5 S+ Sensing end positive
6 Trim Voltage adjustment end
7 S- Sensing end negative
8 Vo- Output negative
