ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
Specifications
Brand Name :
EBUNGE
Model Number :
85 mm acoustic partition walls
Certification :
ISO9001
Place of Origin :
Guangzhou, China
MOQ :
No MOQ, small quantity welcomed
Price :
US $85-102 per square meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000 square meters per month
Delivery Time :
12-20 days
Packaging Details :
Paper carton, outside with wooden boxes
Product name :
Acoustic partition walls
Application :
Function room partitions
Size :
Partition walls customized
Left and right telescoping :
140 mm
Style :
Sliding folding doors
Sample :
Free
Description

Function Room Operable Walls Folding Partition Doors Soundproof Acoustic Partition Walls

Finished project

Thanks for the trust from the client. We finished the packing and shipped to agent's warehouse on March 4th,2019.

This is a project in Lebanon, using the steal materials,including the steel tracks,the steel rollers and the steel haging clips. 8 meters height partitions, 30 meters width, totally 2 sets of walls, around 480 square meters. We just delivered the accessories by air, and we have sent our engineer(Mr. Zeng) to Lebanon to supervise the installation.

Actually our steel system can support 900 KG materials,so that is enough to support the panels for this project.

Do you still worry about the installtion? Please feel free to contact us for more details, our professional team can help you about that.

​​ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors

ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors

Acoustic partition walls accessories

Tracks:Made of good quality anodized aluminium 6063-T5 materials,hanging the acoustic partitions walls panels with wheels.

Wheels/Rollers:It is the carrier for the acoustic partitions walls,let the panels move more flexibly.Pulley bearing is more than 1600 KGS.

Connectors:Made of anodized aluminium 6063-T5 aluminum tracks,“L”, “T”, “＋”types are available.

Rubber/vinyl seal:Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation,wear-resistant.

Rock Wool:Density of 60kg/m3,help us reduce the noise and heat.

Handle:Operate the retractable being up and down.

Retractable mechanism:Control the movement of the top and bottom seal to form a excellent sound insulation performance.

Magnetic Strip:Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the acoustic partition walls.

MDF board:9 mm thickness,density of 760kg/m3,absorbent thickness expansion rate is less than 15%.Formaldehyde emission is 34mg/100g.

ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors

Acoustic partition walls technical details

Model BG65 BG85 BG100
Suspension system Aluminum hanging Aluminum hanging Aluminum hanging
Basic thickness 65mm 85mm 100mm
Total thickness 65/75/85/95mm 80/90/100/110mm 100/120/130mm
Max height Up to 3800mm Up to 6000mm Up to 8000mm
Width 600-1230mm 600-1230mm 800-1230mm

Floor/ceiling sealing

strength

 Telescopic aluminum tube with rubber strip

Side walls sealing

strength

 Double seal tape
Sound insulation level 26dB-30dB 28dB-34dB 32-40dB

ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors

We Offer:

A full professional design service.

Survey and installation guide.

Using top quality materials and components.

A fully experienced work team.

Maintenance contracts to ensure your valuable asset remains in full work order.ISO9001 Acoustic Partition Walls / Function Room Operable Folding Partition Doors
