Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers
Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers
Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers
Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers
Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers
Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers
Specifications
Brand Name :
FOCUS
Model Number :
FM25PSM0412001
Certification :
SGS, FSC，ISO
Place of Origin :
China
MOQ :
1
Max. Parent Web Width :
900mm
Max. Parent Web Diameter :
1000mm
Max. Rewinding Diameter :
2.2Kw
Thickness Range :
40-400gsm
Max. Machine Speed :
200m/min
Overall dimension :
1600*1700*1600mm (1 Ply)
Weight :
1900kg
Voltage :
3 Phase 220V 60HZ or 380V 50HZ
Machine Type :
Flexo Letterpress Printing Machine
Overall Dimension :
4000*1700*1600mm
Power Supply :
220V/50Hz
Max. Unwinding Diameter :
1000mm
Cutting Accuracy :
±0.1mm
Rewind Diameter :
160mm
Slitting Accuracy :
±0.1mm
Description

1. Brief Introduction

FOCUS thermal paper slitting machine is an advanced solution for slitting thermal paper, NCR paper, fax paper, cash register paper, ATM paper, self-adhesive labels, and other types of paper up to 250gsm. It can slit one, two, or three layers of small rolls, with a primary focus on thermal paper and NCR paper. Easy to operate and highly automated, this machine requires minimal input. Only the speed and tension need to be set, after which the system will control the entire operation automatically.

This machine has the features of simple operation and high degree of automation. All parameters are adjusted to the best condition before leaving the factory. The only thing you need to do is to input the data of speed and tension, then the whole machine can be automatically and simultaneously controlled. It becomes more and more popular all over the world.

Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers

2. Technical Parameters

Items Parameters
Max. Parent Web Width 900mm
Max. Parent Web Diameter 1000mm
Max. Rewinding Diameter 200mm
Frequency Inverter Motor 2.2Kw
Thickness Range 40-400gsm
Max. Machine Speed 200m/min
Overall dimension 1600*1700*1600mm (1 Ply)
Weight 1900kg
Voltage 3 Phase 220V 60HZ or 380V 50HZ


Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers

Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers

Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers

Automatic Thermal Paper Slitting Machine for ATM Receipts & Cash RegistersAutomatic Thermal Paper Slitting Machine for ATM Receipts & Cash Registers

Qingdao FOCUS MACHINERY Co., Ltd.

Qingdao FOCUS MACHINERY Co., Ltd, founded in 1990s, was dedicated to manufacture paper machines and provide production line for paper industry.
Based on leading technologies, experiences and knowhow, we could meet a variety of requirements and offer turn key projects.
We are also one of the subsidiary companies of Goodwill Group Limited who was founded in U.K.Since we built more than 30 successful production lines and exporting lots of machines in South America, Asia, Africa, Europe, etc., more customers desired to visit us personally, not only check capacity but also to see our machines how to work and paper quality made by them, so 15 years ago we built paper factory by machines and production lines we produced and designed.
