170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
170t/Min Envelope Die Cutting Machine 3.5KW 500mm Unwinding
Specifications
Brand Name :
PRINTYOUNG
Model Number :
WQM-320G
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
L/C, T/T
Supply Ability :
30 Set/Sets per Month
Delivery Time :
40 days
Packaging Details :
Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Voltage :
220V
Dimension :
2.75m*1.21m*1.76 m
Weight :
1800KG
Warranty :
1 Year
Production Capacity :
20-170 t/min
Max. workable width :
320 mm
Max. unwinding diameter :
500mm
Max. web width :
320 mm
Max. die-cutting width :
300 mm
Max. die-cutting length :
300 mm
Orientation accuracy :
±0.1mm
Total power :
3.5KW
Description
WQM-320G Label (LOGO) Die-cutting Machine

Features

The machine adopts high accurate flat die-cutting system; material forwarding is controlled by servo motor, web-guiding and register are controlled by triple photoelectric eyes. Die cutting, waste rewinding and finished-material rewinding/ sheeter can be finished in one process. It is suitable for die cutting adhesive paper, Dacron label and laser hologram mark. This is the ideal association equipment for the flexo printing machine, silk screen printing machine, gravure printing machine and hologram mark printing machine, and it’s the most efficient machine for printing house.
Technical Parameters
WQM-320G label (LOGO) Die-cutting Machine
Model
320G model
Cutting speed
20-170 t/min
Max. unwinding diameter
500mm
Max. web width
320 mm
Max. die-cutting width
300 mm
Max. die-cutting length
300 mm
Orientation accuracy
±0.1mm
Total power
3.5KW
Machine weight
1800kg
Overall dimensions
2.75m*1.21m*1.76 m
Power supply
220V, 50/60Hz, 1P
Configuration
Applications
It is suitable for die cutting adhesive paper, Dacron label and laser hologram mark. and it is widely used for magazines, paper, books and packs for food, medicine, cosmetic and so on.
FAQ

Q1. Are you a manufacturer or a trading company?

A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?

A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?

A: Normally about 10-20 days.

Q4. What is the delivery time?

A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?

A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?

A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included..

Q7. How about the machine installation and training ?

A: 1)We provide training in our factory for free;
2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?

A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?

A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?

A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material

Q11. What’s the payment term?

A: T/T 50% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?

A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?

A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?

A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
