FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
FM390C Heavy Duty Semi Auto Film Laminator Machine Matt Glossy Hydraulic Oil Heating
Specifications
Brand Name :
PRINTYOUNG
Model Number :
FM-390C
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
US 2500 Set
Payment Terms :
L/C, T/T
Supply Ability :
50 Set/Sets per Month
Delivery Time :
30 days
Packaging Details :
Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Model :
FM-390C
Pressure mode :
Hydraulic
Heating mode :
Oil heating
Max paper size :
380x580mm
Mini paper size :
200x200mm
Operating speed :
0-20m/min
Laminating temperature :
50-120℃
Total power :
3.5kw
Dimensions :
1.85x0.78x1.27m
Pressure :
3~6MPa
Voltage :
220V/50Hz
Feeding mode :
by hands（By Conveyor belt）
With slitting function :
with
Anti-curl function :
with
Rolling-up after lamianting :
No
Automatic disconnecting after laminating :
Yes
Paper thickness :
125~350gsm
Roller diameter :
160mm
Automatic cut after laminating :
Yes
With overlap :
with
Description
Products Description
FM-390C Hydraulic Semi-auto Laminator

Features

FM-390C hydraulic oil heating semi-automatic laminating machine (with pull off), the aircraft covers an area of small,easy to operate, fast, with automatic temperature control, anti-curl set, South Korea imported silicone. Manual pressure. Users only need to enter the meter on the need to break the length of the paper, you can complete the film after the pull off the rear plate with a receipt.The machine to pre-coated polyester film as material, can be widely used in window-type packaging boxes, food boxes,books,drawings, advertisements, certificates and other products of the surface coating, the printed film after the film, waterproof,durable, Clear.
Technical Parameters
FM-390C Hydraulic Semi-auto Laminator
Model
FM-390C
Pressure mode
Hydraulic
Heating mode
Oil heating
Max paper size
380x580mm
Mini paper size
200x200mm
Operating speed
0-20m/min
Laminating temperature
50-120℃
Total power
3.5kw
Dimensions(LxWxH )
1.85x0.78x1.27m
Pressure
3~6MPa
Voltage
220V/50Hz
Feeding mode
by hands(By Conveyor belt)
With slitting function
with
Anti-curl function
with
Rolling-up after lamianting
No
Automatic disconnecting after laminating
Yes
Paper thickness
125~350gsm
Roller diameter
160mm
Automatic cut after laminating
Yes
With overlap
with
Customer
Company Profile
Why Choose Us
Product packaging
FAQ
Q1: Are you a manufacturer or a trading company?
A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.
Q2. What is the machine warranty?
A: One year. After the warranty, we still provide technical support to buyer at low cost.
Q3. What is the production time while placing order?
A: Normally about 10-20 days.
Q4. What is the delivery time?
A: 15-30days after deposit.
Q5. Can your company handle shipping for customers?
A: Yes, just give us destination sea port or container yard.
Q6. Does the packing strong?
A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included..
Q7. How about the machine installation and training ?
A: 1)We provide training in our factory for free
2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.
Q8. Do you have machines in stock?
A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.
Q9. How can you assure the machines’ quality?
A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will
give spare parts for free if machine has any problem.
Q10. Do you inspect machines or test running before packing?
A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material.
Q11. What’s the payment term?
A: T/T 30% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.
Q12. Do you accept factory visiting?
A: Warmly welcome for your visiting.
Q13. How many years are you in printing field?
A: Shanghai company is 12 years old, the factory is more than 20years.
Q14. How many clients do you have?
A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
