Specifications
Brand Name :
XINYUN
Model Number :
XY-TQ-A-D
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
150000 usd
Payment Terms :
T/T
Supply Ability :
500 sets per year
Delivery Time :
70 days
Packaging Details :
Standard export wooden pallet
Rewinding Speed :
200-230m/min
Jumbo roll width :
1200-3000mm
jumbo roll diameter :
1200mm
finished product diameter :
80-300mm
finished product :
toilet paper and lamination kitchen towel and maxi roll
color :
white
Power :
depends on model
Condition :
New
Packing Speed :
8-10 bags per minutes
Cutting System :
Auto cutting
Packing System :
Semi Automatic
Processing Type :
Paper production line
Description

New fully automatic toilet paper/kitchen towel/maxi roll paper tissue making machine line with glue lamination

Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination

Technical performance characteristic:
This production line consists of :
1. XY-TQ-B High speed kitchen towel and toilet paper and maxi roll rewinding machine
2. XY-203 Log roll paper accumulator
3. XY-AI-400 Automatic small kitchen paper and toilet roll band saw Cutting Machine
4. XY-AI-398A Semi automatic 10 rolls kitchen towel and toilet paper packing machine
5. XY-AI-500 Automatic maxi roll band saw cutting machine
From jumbo roll paper into the small toilet paper and kitchen towel and maxi paper towel, the whole line work smoothly and run stable, saving the labor cost and reducing the labor strength. It’s best choice for the producing kitchen towel and toilet paper and maxi roll products.
toilet paper machine,kitchen towel machine,maxi roll machine,toilet paper making machine,maxi roll making machine
Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination
1. XY-TQ-B High speed kitchen towel and toilet paper and maxi roll rewinding machine

Feature and Function

1. Automatic core feeding system, automatic log pusher after rewinding, then rewinding the new log again.
2. Automatic edge-trimming, core feeding, glue spraying and sealing synchronously in one time.

3.Leaving 10-18mm tail, easy to rewind again, so reducing shortcut waste and save the cost.
4. Adopts international advanced PLC programmable controlling technique, man-machine interface operation, data set and parametric fault shows on touch screen.

5. Three horizontal type back stands, pneumatic loading system, with wide driving flat belts; each jumbo roll can be adjusted independently.

6. Embossing Unit: adopt point to point embossing rollers, making the two layers match well, the paper is soft and has clear patterns

7. Adopt jogging switches for wearing the paper, easy and safe to operate.


Product Parameters

Jumbo roll width 1800mm (Other size can be specified)
Jumbo roll diameter max.1200mm(Other size can be specified)
Jumbo roll inner core diameter 3 inches(76.2mm)
Finish product diameter 90-300mm
Finish product inner core diameter 35-90mm
Perforation distance 100-300mm(Other size can be specified)
Production speed 200-230m/min
PLC INVT
Rewinding Unit with core or coreless(need to point out)

Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination

XY-203 Log roll paper accumulator

Function: To make glue laminated log roll dry before cutting and packing, so to get a better effect.
Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination
3. XY-AI-400 Automatic small kitchen paper and toilet roll band saw Cutting Machine
Name
Full Automatic small kitchen paper and toilet roll band saw cuting machine
Cutting blade
band saw blade(size 3750*60*0.6mm)
Finished Product length
250mm
Finished Product Diameter
80-150 mm
Production Speed
80-120 cuts/min
Toilet log length
2200 mm/2850 mm
Finished Products
Small Toilet Paper Roll and kitchen towel
Function
Cut small Toilet Paper Roll and kitchen towel
Type
Paper Roll Cutting Machine

Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination

4. XY-AI-398A Semi automatic kitchen towel and toilet paper packing machine


Model
XY-AI-398A Semi automatic kitchen towel and toilet paper packing machine
Power supply
3Kw 380V 50HZ
Speed
5-12 bundling bag/min
Single roll size
Diameter:Ø90-120mm Height:90-130mm
Bundling Size
L(360-650)*W(180-240)*H(90-130)mm
Machine size
8700*1000*1300mm
Air pressure
0.4-0.5MPA
Weight
800KG


Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination

5. XY-AI-500 Full automatic maxi roll band saw cutting machine
1. Human-machine interaction system
Equipped with industrial-grade touch screen, GUI graphical human-machine interaction interface, and integrated intelligent parameter calculation module. The system has built-in parameter configuration wizard function, supports multi-level menu hierarchical management, and realizes the man-machine interface (Man-Machine Interface) operation mode.
2. Safe operation mechanism
Adopts fully automatic unmanned operation process design, equipped with loop safety protection system (including E-stop emergency stop device), and realizes safety interlock through PLC logic control. The sharpening unit is equipped with an independent safety protection cover, equipped with blade abnormality detection, and blade usage margin detection. Significantly reduce the safety hazards caused by traditional manual intervention.
Nova paper cutting machine,maxi roll cutting machine,paper towel cutting machine,maxi paper roll cutting machine,paper cutting machine
Cutting speed
15-40cuts/minute
Cutting channel
single channel
Cutting blade
band saw blade(18,000--20,000 rolls/blade)
Cutting blade size
6390*90*1.2MM
Log length
≦2200mm or ≦2850mm
Tolerance
±2mm
Cutting length
≦300mm
Cutting diameter
150-300mm(Adjustable)
Thickness of paper core
≦3 mm
Power supply
15KW 3 phase 4line 380V 50HZ
Machine weight
2700KG
Overall size of machine
6546×2651×2635mm


Fully Automatic Toilet Paper / Kitchen Towel / Maxi Roll Paper Tissue Making Machine Line With Glue Lamination


Q: Are you trading company or manufacturer?

A: We are professional tissue converting machine manufacturer with 20 years experience

Q: How long is your machine delivery time?

A: It is 5-10 days if the machines are in stock. or it is 50-60 days if the machines are not in stock

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,70% balance before shipment.

Q: How long is the warranty period of the machine??

A: All machines have a one-year warranty and lifetime technical support.

Q: Does your company provide overseas installation services?

A: After the machines arrive, we shall send technician to install the machines(if need). And the buyer shall pay the technician 100 USD salary per day and round-trip air tickets from Our factory to buyer's factory, the charge of visa, food ,transportation and accommodation in buyer's city.


Fujian Xinyun Machinery Development Co.,Ltd is good at Paper Converting Machinery Manufacture.
Professional supplier of:

1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)
2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)
3) Facial Tissue Machine (2-14 output lanes)
4) Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)
5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)
6) Pocket Tissue Machine(mini and standard size)
7) All kinds of Tissue Paper Cutting and Packing Machine
8) Another Household Paper Equipments and Production Line.
