High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
Specifications
Brand Name :
XINYUN
Model Number :
XY-AI-600
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
13200 usd per set
Payment Terms :
T/T
Supply Ability :
1000 sets per year
Delivery Time :
30-40 days
Packaging Details :
Standard export wooden pallet
Raw material :
50-600gsm
Product size :
Min. slitting width 50mm
Speed :
100-140m/min
Power :
3-4 KW
Weight :
1800 kg
Machine size :
3400*2800*1500mm
Raw material diameter :
1200mm
Description

High speed mother Kraft paper roll rewinding and cutting machine


High Speed Mother Kraft Paper Roll Rewinding Cutting Machine

Kraft paper slitting and rewinding machine is for processing kraft paper jumbo roll into small kraft paper roll, the finished product width is changeable by adjusting the slitting blade. This machine is working with roll core machine.
Kraft paper machine,Kraft paper rewinding machine,Kraft paper cutting machine,Mother Kraft paper machine,Kraft paper roll machine
The main technical parameters

Type XY-AI-1092 XY-AI-1575
Slitting Width Adjustable
Raw Material Size ≤φ1200*1100mm ≤φ1200*1700mm
Production Speed 0~100m/min
Cutting speed 0~80m/min
Paper weight of Jumbo roll 50~600g/m2
Power 10.5KW 12.5KW
Overall dimension(L*W*H) 4300*2200*1400mm 4300*2800*1400mm
Weight about 2500kg about 3000kg
Rewinding Unit Air-shaft
Transmission System Frequency conversion speed regulator
Type XY-AI-2700
Slitting Width Adjustable
Raw Material Size ≤φ1200*2700mm
Machine Speed 0~100m/min
Cutting speed 0~80m/min
Paper weight of Jumbo roll 50~600g/m2
Power 18.5KW
Overall dimension(L*W*H) 4300*3800*1400mm
Weight about4000kg
Rewinding Unit Air-shaft
Transmission System Frequency conversion speed regulator

High Speed Mother Kraft Paper Roll Rewinding Cutting MachinePaper tube core making machine production lineHigh Speed Mother Kraft Paper Roll Rewinding Cutting Machine
Paper core use
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine
High Speed Mother Kraft Paper Roll Rewinding Cutting Machine

Small bobbin tissue paper Toilet paper Kitchen Towel Paper



Q: Are you trading company or manufacturer
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 60-90 days if the goods are not in stock, it is according to
quantity.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.

Fujian Xinyun Machinery Development Co.,Ltd is good at Paper Converting Machinery Manufacture.
Professional supplier of:

1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)
2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)
3) Facial Tissue Machine (2-14 output lanes)
4) Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)
5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)
6) Pocket Tissue Machine(mini and standard size)
7) All kinds of Tissue Paper Cutting and Packing Machine
8) Another Household Paper Equipments and Production Line.
