Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Specifications
Brand Name :
XHY
Model Number :
XHY
Certification :
FSC
Place of Origin :
CHINA
MOQ :
2 TON
Price :
Depending on your quantity and design
Payment Terms :
T/T
Supply Ability :
2000 Tons Per Month
Delivery Time :
15-30 days
Packaging Details :
25KG/Pack 60×60×50Cm
Pulp Style :
Virgin
Feature :
Heat Insulation/Greaseproof
Eco-friendly :
Yes
Shipping :
Via Sea Transport
Printing Type :
Offect Printing/Flexographic Printing
Paper Weight :
150-350 gsm
Key Words :
PE Coated Paper Cup Fans
Printing Logo :
1-7 colors
Use For Packing :
Customized Packing Way Is Acceptable
Size :
Various Sizes Available
Design :
Depending on your requires
Branding :
Can Be Branded With Logo or Word
Material :
100% Virgin Wood Pulp
Coating :
PE coated
Characteristic :
Food Grade/Resuable
Package :
Packed In Outer Carton
Condensation Control :
Yes
Dimension :
Customized
Description
Product Name: Factory Wholesale 6~12oz Sales Food Grade Single Double Side PE Paper Cup Fan
Brand Name XHY
Certification FSC
PE/PLA Weight 9-26gsm
Paper Weight 150-350gsm
Core Diameter 3 inch, 6 inch
Material 100% Wood Pulp
Usage Paper Cups, Hot Drinks, Cold Beverages
Features Heat Insulation, Greaseproof, Waterproof
Color Options 1-7 Colors
Size Range 2.5oz-3

The coating process is a continuous automated production process.

unwinding

The large roll of food grade base paper is placed on the unwinding rack.

preheat

The paper is preheated by a roller to remove surface moisture and raise the temperature of the paper, which helps the plastic melt to adhere better.

Extrusion coating

Core steps. Plastic resin (PE or PLA particles) is added to the extruder.

In the extruder, plastic particles are melted into a viscous flow state through heating and the shearing action of the screw.

Molten plastic is extruded into a uniform thin film through a flat T-shaped die.

This layer of film is directly coated onto the surface of the high-speed passing base paper.

Compression and cooling

The coated paper is immediately passed through a compression device consisting of a cooling steel roller and a rubber roller.

Pressure ensures that the plastic film is tightly bonded to the paper without any bubbles.

The cooling roller rapidly solidifies the molten plastic and firmly adheres to the paper.

collect the papers

The composite material that has been coated is rewound into a large roll, becoming "coated paper".

These large rolls of laminated paper will be transported to the next process for printing, die-cutting (to make fan-shaped sheets), and forming paper cups.

Frequently Asked Questions
Q: Can you do design for me?
A: Yes, our professional designer can make design for free according to your requirements (including size, color, dimension, quantity etc).
Q: How can I get a sample?
A: We provide free samples for you checking the printing and quality of the paper cups, but the express cost need to be collected.
Q: What's the lead time?
A: About 10-15 days.
Q: What's the best price you can offer?
A: Please tell us what's the size, paper material and quantity do you like. And send us your design. We will give you a competitive price.
