Specifications
Warranty :
12 months
Brand Name :
PAPA
Packaging Details :
wooden case
Dimensions :
1400mm x 1200mm x 950mm
Delivery Time :
20 days
Use :
compressing palm sugar powder into solid sugar bricks
MOQ :
1 set
Power Supply :
Electric 380V 3-phase
Certification :
CE
Supply Ability :
20 sets per month
Machine Weight :
750kg
Payment Terms :
T/T
Production Capacity :
150-300 kg/hour
Model Number :
PLD-24-35Y
Place of Origin :
shanghai, China
Output Shape :
square, rectangle, round, custom
Price :
negotiable
Max Pressing Force :
35 Ton
Description

Product Overview

This semi-automatic hydraulic forming machine is developed for compressing palm sugar (gula melaka / jaggery) powder and granules into solid palm sugar bricks and blocks. It is suitable for palm sugar producers, coconut sugar factories and natural sweetener processing plants.
Work flow: Manual feeding → Automatic hydraulic pressing → Embossing logo/pattern → Automatic demolding → Manual collect finished blocks.
Only 1 operator required. Produced blocks feature uniform density, neat shape, smooth surface and low breakage rate; convenient for storage, transportation and retail packaging.

Main Finished Product: Palm Sugar Brick

  • Material: Palm sugar powder, coconut sugar granules, jaggery powder
  • Shape: Square brick, rectangle, round, custom shape
  • Embossing: Custom logo, text, pattern available on block surface
  • Feature: Consistent compactness, neat shape, low breakage rate; convenient for retail packaging and transportation.

Core Advantages

  1. Semi-automatic working, labor-saving
    Manual feeding & finished-product collection; pressing, embossing, demolding complete automatically. One worker can run the whole machine.
  • Adjustable hydraulic pressure & thickness
    Press tonnage and brick thickness are adjustable on control panel, set proper compactness according to palm sugar granule size and humidity.
  • Food-grade stainless-steel contact parts
    All parts touching sugar adopt stainless steel, easy to clean, meet food-production hygiene requirement.
  • Quick-change mold system
    Quick-change mold structure allows fast switch between different brick sizes and shapes for small-batch production.
  • Solid steel frame, stable long-time running
    Heavy-duty welded steel frame ensures stable continuous production, low maintenance, long service life.

    • Working Principle

    1. Worker spreads powder evenly into mold cavity.
    2. Start cycle: hydraulic cylinder goes down to compress powder under preset pressure. Logo/pattern embossed during pressing.
    3. Press head lifts up, automatic ejection pushes finished block out from mold.
    4. Worker takes out finished blocks, moves to packing or curing area.
    5. Refill powder for next production cycle.
    Note: Machine only completes pressing forming. Post drying/curing may be required depending on raw material and binder used.

    Technical Parameters (PLD-24-35Y reference)

    Item Specification
    ModelPLD-24-35Y
    Control modeSemi-automatic hydraulic control
    Power5.0 kW
    Voltage380V 3-phase (customizable 220V / 415V)
    Capacity150-300 kg/h (depends on block size & weight)
    Max pressing force35 Ton (adjustable)
    Block thickness range3-35 mm customizable
    MoldCustom shape & size, logo embossing available
    Machine dimension1400×1200×950 mm
    Net weight750 kg
    Contact materialFood-grade stainless steel
    Warranty12 months (excluding wearing mold parts)

    Applicable Raw Material & Market

    Suitable: palm sugar powder, coconut sugar granules, jaggery powder (dry or semi-dry)
    Target customers: palm sugar producers, coconut sugar factories, natural sweetener processing plants, food factories
    Main export markets: Southeast Asia, South Asia, Middle East natural sweetener markets
    Important Notes
    1. Palm sugar should be granulated/powdered before feeding; high-moisture sticky paste is not suitable.
    2. Machine only presses blocks. Drying/curing is optional depending on sugar humidity.
    3. Molds are wearing parts; customized molds can be supplied per your drawing or sample.

    Our Service

    1. Mold custom: shape, dimension, logo embossed on block surface.
    2. Overseas voltage adaptation.
    3. Factory test run before shipment; test pressing with customer sample material acceptable.
    4. English operation manual, installation guide, video support.
    5. 12-month machine warranty, lifelong technical consultation.

    FAQ

    Q1: Can I make different size sugar bricks on one machine?A: Yes, just replace customized molds.
    Q2: How many workers are needed?A: Only 1 worker for feeding and collecting.
    Q3: Is the machine food-grade?A: Yes, all contact parts use food-grade stainless steel.
    Q4: Can the machine print my brand logo on the sugar brick?A: Yes, we engrave your logo/text on the customized mold.
    Q5: What voltage for overseas market?A: Standard 380V 3-phase, adjustable to local voltage on request.
