split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter
split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter
split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter
split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter
Specifications
Place of Origin :
China
Brand Name :
SUCHEN
Model Number :
DP-58
Usage :
Current
Phase :
Single
Coil Structure :
TOROIDAL
Coil Number :
AUTOTRANSFORMER
Usage: :
Current
Coil Structure: :
Toroidal
Coil Number: :
Autotransformer
widow size: :
50*80 mm
Input range: :
250A -1200 A
Accuracy: :
0.5/ 1.0
Rated output: :
5A / 1A
Case: :
PC/UL94-V0
Packaging Details :
1) There's Foam box which is for DP Series split core current transformer and Accessory.
2) Then put it to Standard Export Cartons.
3) One carton(43*24.5*36cm) is for 18 pieces.
Price :
$108.45/pieces 1-19 pieces
Description
Product Description

split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter

Features

1) Double-screw fastening, safe, easy to install, portable

2) Two built in fixing methods: Base; Busbar mounting

3) Wide inner window, allowing clamping of big cables or bus-bars

4) Wide range of sizes to accommodate all the existing installations.

5) Primary current from 5A to 5000A

Specification

Model Nominal current ratio Burden(VA)/Accuracy
0.5 1.0
DP-58 250/5A / 2.5
300/5A / 2.5
400/5A 2.5 2.5
500/5A 2.5 5
600/5A 2.5 5
800/5A 3.75 5
1000/5A 5 10
1200/5A 5 10

split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter split ct DP-58 current transformer factory 600/5A wound type current transformer for Digital meter
