Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure
Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure
Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure
Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure
Specifications
Brand Name :
D.K.HISTRON
Model Number :
HC-40
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1 Set
Price :
depends on model
Payment Terms :
T/T
Supply Ability :
20 sets/month
Delivery Time :
50days
Packaging Details :
Suitable for long distance transport
Product name :
CNC turret punching machine
Power :
Servo Motor
Punching Capacity :
300 KN
Max Punching Force :
200kN
Bending Material :
stainless steel Aluminum
Repeatability Accuracy :
±0.05mm
Warranty Time :
one year
Return Force :
100 KN
Description
Desktop Hole Puncher Machine Servo CNC Turret Punching Machine
Key Features
  • Standard thick construction using international series dies with long guiding, strong versatility, and high stability
  • O-type closed bed design for excellent rigidity, minimal deformation, and stable feeding support
  • Dedicated CNC punching system with WINDOWS interface for easy learning and operation
  • Wide bed rail span with good level support to ensure precision and high-speed feed stability
  • Advanced software automatically searches clamped positions without manual intervention for high accuracy
Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure
Technical Parameters
Parameter Unit HC-300/HC-400
Punching force KN 300/400
Frame structure "O" type closed frame
Max. machined plate size mm 5000x1250 | 5000x1500 | 5000x2000
Stamping stroke mm 40 | 40 | 40
Max. diameter of one punch mm 88.9 | 88.9 | 88.9
Max. punching frequency hpm 1800 | 1800 | 1800
Max. processed sheet thickness mm 6.35 | 6.35 | 6.35
Workstation piece 28/32 | 28/32 | 28/32
Hole spacing accuracy mm ±0.10 | ±0.10 | ±0.10
Max. punching frequency (1mm pitch, 6mm stroke) hpm 800 | 800 | 800
Max. punching frequency (25.4mm pitch, 6mm stroke) hpm 400 | 400 | 400
Max. speed of sheet movement m/min 106 | 106 | 106
Number of control axes piece 5 | 5 | 5
Turret speed r/min 30 | 30 | 30
Maximum mass of workpiece kg 156 | 156 | 156
Air supply pressure Mpa 0.6 | 0.6 | 0.6
Overall dimensions (LxWxH) mm 5200x5200x2280 | 5500x5200x2280 | 6400x5200x2280
Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure Servo Motor CNC Turret Punch Press 300KN Capacity With O Type Closed Bed Structure
Our Service
  • One-year machine warranty (excluding damage caused by improper operation)
  • Comprehensive documentation including installation drawings, pit design drawings, operation manuals, electrical manuals, maintenance manuals, electrical wiring diagrams, certificates, and packing lists
  • On-site installation guidance and staff training services available
Frequently Asked Questions
What is the delivery time?

30-50 working days, based on factory production order conditions.

How to install the machine?

We provide overseas service with engineers available to guide installation and debugging at your location.

What size machine suits our needs?

We design machines according to your requirements, typically based on your workpiece size, weight, and efficiency needs.

How do you control quality?

One-year warranty with 10 quality control teams checking every part from drawing to finished machine.

What can you buy from us?

CNC Turret Punch Press, CNC bending machine, Fiber Laser Cutting Machine, Bending Automation, Flexible Manufacturing System, Panel bender, and sheet plate automatic production lines.
