Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Specifications
Payment Terms :
T/T
Max Flow Rate :
220m³/h
Model Number :
SJL-7.5
outlet size :
6.0" x 6.0"
Brand Name :
ShuiJingLing
Certification :
CE
Flow Rate :
18m³/h
cable length :
1.2m
MOQ :
1
suction head :
18m
Place of Origin :
Hubei, China
Price :
$350-364
horsepower :
10.2hp
Description
Ultra-light Permanent Magnet Variable Frequency High Pressure Customized Submersible Water Pump
This advanced water pump comes with a built-in permanent magnet variable frequency system, eliminating the need for an external frequency converter or additional control accessories. The integrated variable frequency design simplifies the overall equipment structure, reduces installation costs, and allows users to start and operate the pump directly after wiring.
Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency Ultralight Permanent Magnet Submersible Water Pump Customized Variable Frequency
Technical Specifications
Model Working Voltage Rated Power Maximum Flow Water Lifting Height Caliber Weight
Sjl-3.0 Single phase 220V 3KW 180m³/h 6m 20cm 14kg
Sjl-4.0 Three-phase 380V 4KW 200m³/h 7m 20cm 14kg
Sjl-5.5 Three-phase 380V 5.5kw 210m³/h 9m 20cm 15.5kg
Sjl-7.5-1 Three-phase 380V 7.5kw 220m³/h 12m 20cm 17kg
Sjl-7.5-2 Three-phase 380V 7.5kw 300m³/h 7m 26.7cm 17.5kg
Key Features
  • Built-in permanent magnet variable frequency system
  • No external frequency converter required
  • Integrated variable frequency design
  • Simplified equipment structure
  • Reduced installation costs
  • Direct operation after wiring
  • Ultra-light construction
  • High pressure performance
  • Customizable options available
