The combination of optimized feeding inlet angle and ejection angle greatly enhances the machine's spreading capability. It breaks the limitation of small coverage of ordinary feeders and covers far more pond area with each feeding process.

This electronic timing controller is equipped with an industrial-grade microcomputer control chip, which operates stably, is easy to operate, safe and reliable. The intervals between feedings, feeding times, and the amount of output all can be adjusted.

• Timing control for scheduled feeding
• Normally open function for continuous operation
• Automatic shutdown capability
• Intelligent automatic shutdown after 3 minutes without feed (requires dedicated feeding detection sensor)

1. Connect the power supply and press the "Power On" button. The power indicator light "red light" will turn on.
2. Adjust the corresponding knobs for "interval", "feeding", and "output quantity" to set the parameters suitable for your own needs.
3. If you need to "time" the feeding, simply adjust the timing knob to the corresponding time value. When the timing time arrives, the machine will automatically stop working.
4. If you do not need to "time" the feeding, simply adjust the timing knob to the corresponding "normally open" point. After the material is fed out, the machine will automatically stop working.
5. If during the feeding process, the material is fed out or there is no material, the machine will automatically shut down after 3 minutes without feed. If you need to continue feeding, simply add the material and press the "Power On" button to start feeding again.
6. The method of setting the normally open function: In the normally open working state, as long as it is not manually shut down by pressing the "Power Off" button, the device will automatically turn on when the power is restored.
7. In any situation, if you need to stop the feeding process, simply press the "Stop" button to halt it.
