Curved Lithium Polymer Battery
Curved Lithium Polymer Battery
Specifications
Brand Name :
ODM
Model Number :
3.7V 151025 12mAh
Certification :
IEC62133, UN38.3, MSDS
Place of Origin :
Guangdong, China (Mainland)
MOQ :
3000
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
50,000pcs/day
Delivery Time :
15-20 days for samples, 25-35 days for mass production
Packaging Details :
plastic pallet, standard export carton
Type :
Lithium Polymer
Cell Model :
151025
Nominal Voltage :
3.7V
Nominal Capacity :
12mAh
Items :
151025 12mAh Special Shape Curved Rechargeable Lithium Battery
Application :
Intelligent Ring
Keywords :
Lipo Battery, Lithium Polymer Battery, Lithium Battery, Special Shape Lithium Battery, Curved Battery
Protection :
Built-in PCM
Standard Discharge Current :
0.5C, 6mAh
Standard Charge Current :
0.5C, 6mAh
Certificate :
IEC62133, UN38.3, MSDS
Cycle :
500 times
Warranty :
1 year
Description

3.7V 151025 12mAh Special Shape Curved Rechargeable Lithium Battery for Intelligent Ring

Special Shape Curved Rechargeable Lithium Battery, widely use in wearable product like Intelligent Ring.

We have more than 1000 models for your choosing. And can also produce customized cells according to your requirement.

Features of Special Shape Curved Rechargeable Lithium Battery

Long cycle life
After 1000 cycles, the capacity maintained over 80%.
Wide operating temperature
Can be used at temperature -50 ℃~50 ℃ or 20 ℃~80 ℃.
Ultra-thin
The thickness can be as thin as 0.4mm.
High energy density
Specific energy density up to 460Wh/L light weight.
Ultra-Safe
Meet the requirements of ROHS, CE, UL, UN38. 3, MSDS and other certification.
Fast charge ability
Support 3C quick charge, maximum C-rate can reach 40C.

Specification of 3.7V 151025 12mAh Special Shape Curved Rechargeable Lithium Battery
No.
Item
General Parameter
Remark
1.1
Description
Ultra Small Curved Battery 12mAh for wearable devices
Prismatic soft package
1.2
Cell Model
151025-3.7V 12mAh
　
1.3
Typical Capacity
12mAh
　
1.4
Typical Voltage
3.7V
　
1.5
End of Charge Voltage
4.2V
　
1.6
Charge Current
0.2C
　
1.7
Charging time
5-6 Hours
　
1.8
End discharge Voltage
3.0V
　
1.9
Max continuous charge current
2C (20mA)
　
2
Maximum Continuous Discharging Current
2C (20mA)
　
2.1
Over-discharge Voltage Protection cell
3.0V
　
2.2
Over-Current Discharge Protection
1A
　
2.3
Short circuit protection
With protection
　
2.4
Dimension
1.5*10*25mm
　
2.5
Weight
3gs
　
2.6
Operation Temperature Range
Charge 0~45 C, Discharge -20~60 C
 　

Curved Battery List

Model No. Voltage (V) C-rate Capacity (mAh) IR (mΩ) Weight (g) Type
PAC2524038-T1A 4.35 10C 185 ≤80 4.1±0.5 curved battery
PAC3024038-E1A 4.35 8C 250 ≤70 5.3±0.5 curved battery
PAC3020035-11A 4.35 1C 200 ≤75 3.9±0.5 curved battery
PAC4024025-13A 4.35 1C 225 ≤100 4.1±0.5 curved battery

Special Shape Curved Rechargeable Lithium Battery Application

PAC produces high-performance curved batteries for Smartwatches, wristband, medical equipment, communication, smart rings, smart glasses, WIFI audio, wearable multi-touch projectors, charging boots, workout clothes, navigation shoes, i-watches, sports bracelets, etc.

Our R&D team works closely with clients to provide the best solution for their batteries.



Special Shape Curved Rechargeable Lithium Battery Delivery

• By Air Door to Door Service

• By Sea Door to Door Service

• By Express: EMS, TNT, UPS, FedEx
