Specifications
Model Number :
7E4-NO-10 (PN: 058-0700-200)
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-5 work days
Nominal Range :
0 ~ 10 ppm
Maximum Overload :
20 ppm
Sensitivity (20℃) :
0.40 ± 0.20 μA/ppm
Response Time (T90) :
≤ 45 s
Zero Signal (20℃) :
< ±500 nA
Baseline Shift (-20℃ ~ 50℃) :
< 100 ppb (After compensation)
Description

7E4-NO-10 (PN: 058-0700-200) FOUR ELECTRODE NO SENSOR The Design Optimizes The Sensor Sensitivity Accuracy And Long-Term Stability

Environmental:

Temperature Range -20℃ ~ 50℃
Pressure Range 1 ± 0.1 atm
Humidity Range 15% ~ 90%RH non-condensing

Cross-Sensitivity Data:

Gas Concentration (ppm) Output Signal (ppb NO equivalent)
Sulfur Dioxide 5 54.7
Ammonia 20 0.0
Hydrogen Sulfide 5 0.0
Carbon Monoxide 5 0.0
Nitrogen Dioxide 5 92.7
Hydrogen 100 20.5
Carbon Dioxide 30,000 0.0
Ozone 0.5 0.0
Chlorine 5 43.0

Installation:

Output signals from the sensor pins are different. Inappropriate use of the pins in product design will affect the sensor functionality. Exposure to high concentrations of solvent vapors should be avoided under any condition. Mechanical overstress may cause deformation or cracks of the plastic enclosure of the sensor. If the sensor is used in extreme environmental conditions, please contact us for more details.

Product Dimensions:

7E4-NO-10 (PN: 058-0700-200) FOUR ELECTRODE NO SENSOR The Design Optimizes The Sensor Sensitivity Accuracy And Long-Term Stability

7E4-NO-10 (PN: 058-0700-200) FOUR ELECTRODE NO SENSOR The Design Optimizes The Sensor Sensitivity Accuracy And Long-Term Stability
