MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
Specifications
Model Number :
MICS-VZ-89TE
Place of Origin :
USA
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000PCS
Delivery Time :
5-8 work days
Packaging Details :
Standard packaging
Supply Voltage :
3.3V DC regulated ± 5%
Operating Power :
125 mW
Warm - up Time :
15 min
Operating Temperature :
0 °C to 50 °C
Operating Humidity :
0% RH to 95% RH
Storage Temperature :
- 40 °C to 80 °C
Description

MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring

Features:

  • Calibration - free: Does not require regular calibration, reducing maintenance costs and complexity.
  • Low Power: Consumes only 125 mW of power, making it suitable for battery - powered or low - power applications.
  • Wide VOCs Detection Range: Can detect TVOCs in the range of 0 - 1000 ppb, covering a wide variety of indoor air quality monitoring scenarios.
  • High Sensitivity: Can accurately detect small changes in gas concentrations, providing reliable air quality information.
  • High Resistance to Shocks and Vibrations: Can withstand harsh environmental conditions during transportation and operation, ensuring stable performance.

Application Areas:

  • Indoor Air Quality Monitoring: Used to monitor the air quality in indoor environments such as offices, homes, and public buildings to ensure a healthy living and working environment.
  • Vehicle Cabins: Can be installed in vehicle cabins to monitor the air quality inside the car, providing a comfortable driving environment.

Supply Voltage 3.3V DC regulated ± 5%
Operating Power 125 mW
Warm - up Time 15 min
Operating Temperature 0 °C to 50 °C
Operating Humidity 0% RH to 95% RH (non - condensing)
Storage Temperature - 40 °C to 80 °C
Storage Humidity 0% RH to 95% RH (non - condensing)
Detectable Gas Range TVOC 0 - 1000 ppb, CO2 equivalent 400 - 2000 ppm
Output Type Pulse - Width Modulation (PWM) and I2C

MICS-VZ-89TE Indoor Air Quality Module For Indoor Air Quality Monitoring
