YJJ GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor for Flue Gas Monitoring in Pressure Range of 800 to 1200 mbar
YJJ GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor for Flue Gas Monitoring in Pressure Range of 800 to 1200 mbar
YJJ GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor for Flue Gas Monitoring in Pressure Range of 800 to 1200 mbar
YJJ GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor for Flue Gas Monitoring in Pressure Range of 800 to 1200 mbar
YJJ GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor for Flue Gas Monitoring in Pressure Range of 800 to 1200 mbar
YJJ GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor for Flue Gas Monitoring in Pressure Range of 800 to 1200 mbar
Specifications
Brand Name :
YJJ
Model Number :
GS+5CO
Place of Origin :
Britain
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
22000
Delivery Time :
5 to 8 working days
Packaging Details :
Pouching
Pressure range :
800 to 1200 mbar
Working humidity :
15% to 90% RH
Long-term output drift / per year :
< 5%
Working life / in air :
> 24
Guarantee :
12
Repeatability / CO equivalence :
< ±2%
Description

Product Description:

GS+5CO 5 Series Electrochemical Carbon Monoxide Sensor Is Used In Field Of Flue Gas Monitoring

Features:

GS+5CO is a four-electrode carbon monoxide sensor that takes hydrogen compensation into account. It is optimally designed and complies with the strict requirements of EN50379 Part 1. It is applied in the field of strict flue gas monitoring.

Sensitivity / nA/ppm: 75 ± 25

Baseline range (clean air) / ppm: ± 5

Filtering capacity / ppm-hour: > 100,000 acidic gases

T90 response time / second: < 40

Measurement range / ppm: 0 - 4000

Overload / ppm: 10000

Is H2 compensation available? : Yes

Repeatability / CO equivalence: < ±2%

Recommended load resistance / ohm: 10

Resolution / ppm typical value: < 1

Continuous operating temperature: -30°C to +50°C

Pressure range: 800 to 1200 mbar

Working humidity: 15% to 90% RH

Long-term output drift / per year: < 5%

Recommended storage temperature /: 0°C to 20°C

Working life / in air: > 24

Guarantee: 12

Specifications:

Temperature Compensation -40℃ ~ 125℃
Operating voltage 3.0V/(5.0V)
Analog voltage output 0.4 - 2.0 VDC
Over-range output 2.0 V - 2.4 V)
