WS-M1300 IAQ Indoor Air Quality Monitor

Description:

This monitor is mounted BLE, detects temperature, humidity, PM, CO2, TVOC, CH2O, and CO in indoor air quality and sends the detection data via BLE. Optional color is white and black. Material is ABS.

Mounted sensors:

Temperature/humidity, PM, CO2 sensors are standard mounted, and TVOC, CH2O, CO sensors are optional mounted according to the product code. In addition, NTC is mounted to correct the temperature so that the detection results of the temperature and humidity sensor match the indoor temperature.

Environment Condition:

• 1) Operating temperature:0-50℃
• 2) Storage temperature:0-25℃
• 3) Operating humidity:0-90%Rh
• 4) Usage environment:Office with commercial air conditioner
• 5)Operating time rating:Continuous
• 6) Product life:2 years

Power supply:

The power supply for the internal 5V line is the output voltage of USB adapter (VBUS: 5V±5%). The power supply for the internal 3.3V line is 3.3V±10% generated from the output voltage of USB adapter (VBUS).

The power supply for the RTC is 3.3V generated from VBUS when power is supplied from USB adapter, and when not, it is the voltage of the button battery. The button battery life is more than 5 years.

BLE communication:

This product work BLE communication as peripheral device.

If the connection is disconnected, to send the data after reconnecting.

Data Storage:

This product storage the sensor data every 10 minutes in flash memory. Sensor data can be saved for the past 30 days.

Application:

Indoor air quality monitoring for smart home, smart buildings, etc.

Features:

• Multi-Parameter Air Quality Monitoring
• Advanced Technical Features
• Reliable Hardware & Build Quality
• High Accuracy & Stability
• Versatile Applications
• Longevity & Low Maintenance
