Specifications
Model Number :
6810883
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, ,
Supply Ability :
5000pcs
Delivery Time :
3-5work days
Packaging Details :
Paper box
Measurement Range :
0 - 200 ppm
Resolution :
1 ppm
Response Time :
15 s
Warranty :
3 years
Description

6810883 Gas Sensor Excellent Long - term Stability

General Information2:

  • Model: 6810883
  • Brand: Draeger
  • Product Name: XXS Hydrogen Sulfide (H₂S) Sensor
  • Compatible Instruments: X - am 2000, X - am 2500, X - am 3500, X - am 5000, X - am 5600, PAC 7000 series gas detectors

Technical Parameters24:

  • Measurement Range: 0 - 200 ppm
  • Resolution: 1 ppm
  • Response Time: 15 s
  • Sensor Type: Electrochemical
  • Temperature Range: -20°C to 48.9°C (-4°F to 120°F)
  • Warranty: 3 years

Features:

  • High Sensitivity and Selectivity: It has high sensitivity to hydrogen sulfide and can accurately detect low - concentration H₂S. It also has good selectivity, which can minimize the interference of other gases and improve the accuracy of detection.
  • Fast Response: The electrochemical sensor technology enables a fast response to changes in hydrogen sulfide concentration, and can quickly issue an alarm when the H₂S concentration exceeds the standard, so as to protect the safety of personnel and the environment in a timely manner.
  • Compact Design: The XXS series sensors are remarkably compact, which is convenient for installation and use in various gas detection instruments, and is suitable for different application scenarios.
  • Excellent Long - term Stability: It has excellent long - term stability, which can ensure the accuracy and reliability of detection results during long - term use, reduce the frequency of calibration and replacement, and save operating costs.

Parameter

Details
Measurement Range 0–200 ppm
Resolution 1 ppm
Sensitivity High selectivity for H₂S, minimal cross-gas interference
Response Time (T90) ≤ 15 seconds
Temperature Range -20°C to 48.9°C (-4°F to 120°F)
Humidity Range 15–95% RH (non-condensing)
Operating Pressure 860–1,060 hPa (sea level ±10%)
Sensor Type Electrochemical
Expected Lifespan > 3 years
Warranty 3 years
Compatibility - X-am Series: X-am 2000, 2500, 3500, 5000, 5600
- PAC Series: PAC 7000
Installation Plug-and-play, user-replaceable
Certifications Compliant with ATEX, IECEx, and relevant safety standards
Dimensions Compact design (specified in detector manuals)
Weight Lightweight (integrated with detector)
