YJJ SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect Sensor
YJJ SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect Sensor
YJJ SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect Sensor
YJJ SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect Sensor
Specifications
Brand Name :
HONEYWELL
Model Number :
SS411A
Place of Origin :
United States
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
22000
Delivery Time :
5 to 8 working days
Packaging Details :
Box pack
Sensing Range :
6mT Trip, -6mT Release
Test Condition :
25°C
Voltage - Supply :
3.8V ~ 30V
Current - Supply (Max) :
10mA
Current - Output (Max) :
20mA
Operating Temperature :
-40°C ~ 150°C (TA)
Description

Product Description:

SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect Sensor

Features:

Latch position sensor integrated circuit

SS400 series, SS500 series

Integrated circuits of single-pole digital Hall effect sensors with low, medium and high magnetic field intensities. Flat TO-92 style, SOT-89B package. Digital current sink output

The SS400 series sensor integrated circuit is a small general-purpose digital Hall effect sensor. It operates by the magnetic field provided by a permanent magnet or an electromagnet, and is used to respond to the alternating north and south magnetic poles or only to the south magnetic pole. Bipolar latch magnets and unipolar magnets are available for selection.

The bandgap adjustment function helps ensure stable operation within the power supply voltage range of 3.8Vdc to 30Vdc. These sensors can achieve a continuous current output of 20 mA and can cycle at a current of up to 50 mA. Its ability to operate at 3.8V voltage can be used in many potential low-voltage applications.

The digital open-circuit collector current sink output can be easily connected and used with various electronic circuits.

To provide reliable products and maintain consistent quality, the SS400 series has been tested at both 25°C [75°F] and 125°C [257°F]. All the catalogue products in this series can operate at a temperature of 150°C [302°F].

For the sake of design flexibility, the following pins and packaging options are provided:

Straight pins, 14.99mm [0.59 inches] in length, packed in bulk or in roll-up boxes

Straight pins, 18.7mm [0.735 inches] long, bulk packaging

Formed pins, 14.99mm [0.59 inches] in length, packed in bulk or in roll form boxes

Specifications:

Sensor type Magnetic sensor
Sensing range ±50mT
Work Point (BOP SS411A
Power supply voltage 30V

YJJ SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect SensorYJJ SS411A Straight Pin 14.99mm Digital lock Single-Pole Hall Effect Sensor
