YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
Specifications
Brand Name :
YJJ
Model Number :
4CL2-10 062-0100-000
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2200
Delivery Time :
5 to 8 working days
Packaging Details :
Canned
Range :
0 to 10 ppm
Maximum load :
50 ppm
Sensitivity (20℃) :
-0.75 ± 0.15 μA/ppm
Response time (T90) :
≤ 30 seconds
Baseline (20℃) :
< ±0.2 μA
Resolution :
0.05 ppm
Description

Product Description:

4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas

Features:

Product Description

This product is used to measure the concentration of chlorine gas and can replace the standard four-series chlorine gas electrochemical sensor with pins.

Performance parameters

The range is 0 to 10 ppm

Maximum load: 50 ppm

Sensitivity (20℃) : -0.75 ± 0.15 μA/ppm

The response time (T90) is ≤ 30 seconds

Baseline (20℃) < ±0.2 μA

Baseline drift (-40℃ to 50℃) < 1 ppm

Resolution 0.05 ppm

Linearity Linear

Bias voltage: 0 mV

Working environment

Temperature range: -40℃ to 50℃

The pressure range is 1 ± 0.1 standard atmosphere

Humidity range: 15% to 90%RH (no condensation)

Lifespan

Long-term stability < 2% signal value per month

Storage temperature: 10℃ to 30℃

Service life: 2 years (in the air)

Storage time: 6 months (in dedicated packaging boxes)

The warranty period is 12 months

Intrinsically safe data

The maximum current is less than 0.2 mA when there is 50ppm of chlorine gas

The maximum open-circuit voltage is 1.3V

The maximum short-circuit current is less than 1.0 A

Physical properties

Shell material: ABS

Weight: 5 grams

No directionality

Specifications:

Storage temperature 10℃ to 30℃
Service life 2 years (in the air)
Storage time 6 months (in dedicated packaging boxes)
maximum open-circuit voltage 1.3V
Shell material ABS
Weight 8 grams

YJJ 4CL2-10 062-0100-000 Electrochemical Chlorine Gas Sensor Is Used To Measure Concentration Of CL2 Gas
