110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments
Specifications
Brand Name :
SPEC
Model Number :
3SP-O3
Place of Origin :
UK
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-5workingdays
Packaging Details :
Standard Package
MOQ :
1
Price :
Negotiable
Supply Ability :
3000PCS/Months
Lower Detection Limit :
< 20 Ppb (instrumentation Dependent)
Measurement Range :
0 To >20 Ppm
Power Consumption :
10 To 50 UW (circuit & Ambient O3 Dependent)
Sensitivity nA/ppm @ 5ppm :
-60 +/- 10 NA/ppm
Resolution :
< 20 Ppb (instrumentation Dependent)
Operating Temperature Range :
-30 To 50 C (-20 To 40 C Continuous)
Expected Operating Life :
> 5 Years (10 Years @ 23+/-3C; 40+/-10% RH)
Operating Humidity Range :
Non-condensing 0 To 100% RH (15 To 95% Continuous)
Description

110-406 3SP-O3 Ozone Gas Sensor Electrochemical Sensitivity for Non Condensing Environments

BENEFITS
• Small Size with Low Profile (20x20x3 mm)
• Long Life (10 years expected life)
• Fast Response (< 15 seconds)
• Low Power Consumption
• Individually Calibrated (NIST Traceable)
• ROHS Compliant
• Improved stability and ppb performance

APPLICATIONS
• Air Quality Monitoring*
• Industrial Safety
• Air Purification Control

Measurement Range 0 to >20 ppm
Lower Detection Limit < 20 ppb (instrumentation dependent)
Resolution < 20 ppb (instrumentation dependent)
Response Time < 15 seconds typical
Sensitivity nA/ppm @ 5ppm -60 +/- 10 nA/ppm
