Specifications
Model Number :
AGS02MA
Place of Origin :
CN
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000pcs
Delivery Time :
3-5work days
Packaging Details :
Paper box
Supply Voltage :
3.3~5.5 VDC
Operating Current :
28 ±5 mA
Preheating Time :
≥120 s
Sampling Period :
≥2 s
Response Time (T90) :
<60 s
Recovery Time :
<90 s
Description

AGS02MA MEMS TVOC Gas Sensor for air Quality Monitoring in Consumer and Industrial Devices

Key Applications:

  • Air purifiers, fresh air systems, and HVAC controls
  • Smart home appliances (e.g., air quality monitors, humidifiers)
  • Indoor air quality (IAQ) monitoring devices
  • Industrial leak detection for light VOCs
  • Automotive cabin air quality sensors
  • Consumer electronics with air quality feedback

Features:

  • Calibrated Digital Output: Factory-calibrated I2C signal for plug-and-play integration, no complex analog circuitry.
  • Long-Term Stability: Low drift and >5-year service life in clean air reduce maintenance frequency.
  • Fast Response/Recovery: T90 <60 s and recovery <90 s for real-time VOC changes.
  • Wide Voltage Compatibility: 3.3–5.5 VDC operation suits 3.3 V/5 V microcontrollers.
  • Cost-Effective: Low BOM cost with minimal external components (only pull-up resistors for I2C).
  • Compact Form Factor: 12.5×5.8×2.5 mm footprint for space-constrained designs.

Standard Test Gas Ethanol
Output Interface I2C (address 0x1A, max 30 kHz)
I2C Commands Write: 0x34; Read: 0x35
Supply Voltage 3.3–5.5 VDC
Operating Current 28 ±5 mA
Preheating Time ≥120 s
Sampling Period ≥2 s
Response Time (T90) <60 s
Recovery Time <90 s
Operating Temperature 0–50°C
Operating Humidity 0–95% RH (non-condensing)
Storage Temperature -20–60°C
Service Life >5 years (@25°C, clean air)
Dimensions (mm) 12.5 × 5.8 × 2.5
