Specifications
Model Number :
SS441R
Place of Origin :
USA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000pcs
Delivery Time :
3-5work days
Packaging Details :
Paper box
Wide operating voltage range :
3V ~ 24V DC
Extreme temperature tolerance :
-40°C ~ +150°C
encapsulation :
TO-92
Output Logic Level (Low) :
0.4 V DC
Description

SS441R Unipolar Hall-Effect Sensor for Door/lid/cover Closure Detection Flow Rate Sensing Medical Equipment

Features :


High sensitivity: Typical operate point 75 G (25°C)
Wide voltage range: 3.0 to 24 VDC
Fast response: 1.5 μs switching speed
Low power: Nominal supply current 3.5 mA
Temperature range: -40°C to +150°C
Built-in reverse polarity protection
Thermally balanced IC for stable performance
RoHS compliant
Package: Flat TO-92 (3-pin through-hole)
Output: Current sinking (20 mA max)


Applications :


Position & proximity sensing
Door/lid closure detection
Speed/RPM sensing (fans, motors)
Flow rate monitoring
Valve/damper position control
Robotics & industrial automation
Medical equipment (hospital beds, diagnostics)
Consumer electronics & HVAC systems

Parameter

Min

Typ

Max

Unit

Test Condition
Operating Supply Voltage 3 - 24 V DC -
Supply Current - 3.5 8 mA Vcc=24V, no load
Maximum Output Current - - 20 mA Open-collector output
Magnetic Operating Point (Bop) 35 75 135 G 25°C, south pole
Magnetic Release Point (Brp) 10 - 120 G 25°C
Magnetic Hysteresis (Bh) - 40 - G Bop - Brp
Output Fall Time - - 1.5 μs -
Operating Temperature Range -40 - +150 °C Full voltage range
Storage Temperature Range -40 - +150 °C -
Output Logic Level (Low) - 0.4 - V DC Iout=20mA
Pin Spacing - 2.54 - mm TO-92-3 package
