CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
Specifications
Model Number :
CAFS1000A
Price :
Negotiable
Packaging Details :
Standard Box
Supply Ability :
1000pcs/Month
Pressure resistance :
Max. 0.3 MPa
MOQ :
1
Standard range :
10–1000 kg/h (air mass flow rate)
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Accuracy :
±2% FS; repeatability <0.5%
Delivery Time :
3-5Workingdays
Air velocity range :
0–60 m/s
Place of Origin :
China
Brand Name :
YJJ
Description

CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type

Core Product Advantages
Thermal MEMS silicon chip design; features no fragile membranes and offers resistance to oil contamination and airflow shock.
Factory-calibrated for linearity; exhibits minimal zero-point drift and excellent long-term stability.
Automotive-grade wide-temperature design; suitable for automotive air intake, industrial ventilation, and gas detection applications.
Designed for DN6 pipe diameters; features an inline insertion mounting style compatible with mainstream air intake systems.


III. Typical Application Scenarios
Automotive engine EFI (Electronic Fuel Injection) system air mass measurement and ECU fuel injection control.
Exhaust gas monitoring, boiler air supply, and HVAC airflow monitoring.
Air compressor and fuel cell intake flow monitoring; industrial clean gas mass flow measurement.
Environmental wind tunnel testing; fresh air system airflow measurement and control.


IV. Differences Between Series Models
CAFS1000A: Measurement range 10–1000 kg/h (high flow).
CAFS1000B: 10–800 kg/h.
CAFS1000C: Small-to-medium flow specification; suitable for small-displacement equipment.

Specification:

Power supply 7–24 VDC (typically 12V automotive power); operating current <50mA
Output Default 1–5V analog linear voltage output; optional frequency signal output
Response time Typically 20ms (customizable to 15ms)
Protection rating IP40; ABS housing
Operating temperature -40°C to +125°C (automotive-grade wide temperature range)
Humidity 0–100% RH (condensation allowed; freezing prohibited)
Shock resistance 100g; solid-state silicon sensing core; dust-resistant and resistant to clogging or damage

CAFS1000A Mass Air Flow Sensor MEMS Air Flow Meter General-Purpose Industrial Type
