Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
Specifications
Brand Name :
ESTEL
Model Number :
131080921050001
Certification :
ISO9001, CE, 3C, FCC, TLC, IP55
Place of Origin :
Shenzhen, China (Mainland)
MOQ :
1 set
Price :
358-2143 usd
Payment Terms :
T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability :
5,000 sets per month
Delivery Time :
15-20 working days
Packaging Details :
Wooden case
External size :
W*D*H 800*900*2100mm
Material :
Galvanized steel
Cabinet Lock :
Anti-theft three point lock(support padlock)
Cable Inlets :
From cabinet bottom
Mounting type :
Floor mount
Cooling system :
Air conditioners and fans
Certificates :
CE
Protection Level :
IP55
cabinet :
Outdoor telecom cabinet
Description

Green Color 42U Sunproof Rainproof Air Conditioner Cooling Outdoor Telecom Cabinet 19 Inch Rack

1.Cabinet Overview

This series enclosures are the ultimate choice for outdoor racking requirements. Being made of galnarized steel,it’s strong enough to rack even the heaviest equipment.The enclosures includes the standard features to meet the needs of customers, a 3- point locking system and different accessories installed in the 19 inch rack inside. For those who need more than just standard enclosure, this series can also offer a truly the security of customized solution with lots of available options, providing a climate-controlled environment for any electronic equipment, electrical load panels and cable entry solutions.

2.Cabinet Specifications

External Size W*D*H 800*900*2100mm.

Color

Green color

Cabinet Layout

 One compartment for installing 19” equipment

Material

Galvanized steel, 1.5mm thick outer plate, 0.8mm thick inner plate

Equipment Installation Method

19” rack
Protection Level

IP55
Cabinet Inlets From cabinet bottom
Illumination/lighting DC48V LED lamp
Heat Insulation PEF

Grounding Protection

 Copper bar

Cabinet Lock

 3 point door lock

Cooling System

Air conditioner and Fan

Coating

 Anti-corrosion outdoor powder coating

Accessories Options

PDU, Environment monitoring system

Alarm sensors

The door sensor, water sensor, smoke sensor, temperature and humidity sensor
Flame retardant Comply with GB5169.7 test A
Door type With 1 front door
Package Wooden case with pallets
Certificates CE

3.Cooling system

Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof

4. Cable entry holes

There are entrance holes individually for feeder cable and other external cables.

.

Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof

5. Theft Proof Design

5.1 Three theft lock theft proof design

Damage resistance of the theft proof lock meets GA/T 73-1994 "Mechanical Anti-theft Lock"class B requirement,supporting padlock.

5.2 Connection and fastening

(1) Use anti-loose threaded connection as structure and bearer connection.Anchor bolt for fixing cabinet use hot dip galvanized bolts.

(2) Door hings use inner hinge mode.

6.Product pictures

Green Color Outdoor Electrical Cabinets And Enclosures 42U Sunproof Rainproof
