Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
Specifications
Brand Name :
ESTEL
Model Number :
ET7575175-UP-S1
Certification :
ISO9001, CE, RoHs
Place of Origin :
Shenzhen, China (Mainland)
MOQ :
1
Price :
715-4286 usd
Payment Terms :
L/C, D/A, D/P, T/T, etc
Supply Ability :
100,000 sets per month
Delivery Time :
3-5 working days
Packaging Details :
wooden case/carton case/
External Dimension :
W×D×H 750×750×1750mm
Layout :
The upper cabin is for 19” equipment, the lower cabin is for battery
Door :
One front door
Material :
Galvanized steel, single wall
Ingress Protection :
IP55
Cooling :
DC48V fan
Relative Humidity :
5% ~ 100%
Working Temperature :
-40°C ~ +55°C
Description

Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet

1. Applications

The ET7575175-UP-S1 Outdoor Telecom Cabinet is mainly used in wireless communication base station:
(1) Access/transmission switching station
(2) Emergency communication/transmission
(3) 4G,5G system
(4) Communication/network integrated service
(5) The cabinet is suitable for outdoor environment, such as road side, park, building roof, mountain area, flat ground, etc. The cabinet can be installed with base station equipments, power supply equipments, batteries, temperature control equipments, transmission equipments and other equipments, or the cabinet can reserve installation space and heat exchange capacity for the above equipments, providing reliable mechanical and environmental protection for normal operation of the internal equipments.

2. Feature

  • IP 55 rating (Optional IP65 available upon request)
  • Fan cooling
  • Multi-point lock rod system as standard
  • 19” panel mounting posts as standard with optional ETSI
  • Doors secured with steel dead locking system lock (support PADLOCK)
  • Multi-stage cleaning and pre-treatment prior to the application of a 120micron powder coating
  • Manufactured from heavy gauge galvanized material
  • Installed using “direct bury” in-ground root or overground plinth system
  • Includes many anti-vandal features within the construction
  • Used in station, carpark, trackside applications for housing and protecting active communications, UPS, DVR and sensitive electronic equipment
  • Cable entry is via the base as standard with bottom entry available

3. Specifications


(1) Technical Parameters

Item Type Technical Parameter
Structure Dimension External Dimension: W×D×H 750×750×1750mm
Layout One compartment, the upper cabin for installing 12U 19” equipment, the lower cabin for installing two layers battery
Equipment Installation Method 19” rack, battery tray
Door With one front door, and anti-theft three point lock for outdoor cabinet (support padlock)
Material Galvanized steel, single wall
Ingress Protection IP55
Temperature Control Cooling DC48V fan
Temperature Temperature Working Temperature: -40°C ~ +55°C
Storage Temperature: -50°C ~ + 70°C
Transport Temperature: -50°C ~ +70°C
Humidity Relative Humidity 5% ~ 100%
Pressure Air Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity Solar Radiation Intensity 1120 ×(1±5%)W/m2


(2) Accessories List

No. Item Quantity Unit Specs
1 Outdoor Telecom Cabinet 1 Set

(1) External Dimension: W×D×H 750×750×1750mm

(2) One compartment,the upper part for installing 19” equipment, the lower part for installing battery

(3) With one front door, and anti-theft three point lock for outdoor cabinet (support padlock)

(4) Material: galvanized steel, single wall without heat insulation

(5) IP grade: IP55
2 Fan 1 Set Two DC48V fans with one temperature controller
3 LED Lamp 1 Set DC48V, with lamp switch
4 Package 1 Set Wooden case with pallet

4. Drawing for Outdoor Cabinet

Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet


5. Outdoor Telecom Cabinet Pictures

Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet


6. Our Factory and Product

Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet

Single Wall Steel IP55 Outdoor Power Enclosure Rainproof Power Supply Cabinet
