5db Optical Variable MU Singlemode Fiber Attenuator
5db Optical Variable MU Singlemode Fiber Attenuator
5db Optical Variable MU Singlemode Fiber Attenuator
5db Optical Variable MU Singlemode Fiber Attenuator
5db Optical Variable MU Singlemode Fiber Attenuator
5db Optical Variable MU Singlemode Fiber Attenuator
Specifications
Place of Origin :
CHINA
Brand Name :
SKYLYNN or OEM, ODM
Certification :
ISO, ROHS, CE
MOQ :
10PCS
Packaging Details :
PP BAG, INNER BOX, OUTER BOX
Delivery Time :
2-7 DAYS
Payment Terms :
T/T, L/C, WEST UNION
Supply Ability :
800,000
Model NO. :
ATTNMUU01
Description

MU Fiber Optic Attenuator

MU attenuators are devices which reduce the strength of a fiber optic signal within a fiber optic network. Attenuators are usually used when the signal arriving at the receiver is too strong and hence may overpower the receiving elements. This may occur because of a mismatch between the transmitters/receivers (transceivers, media converters), or because the media converters are designed for a much longer distance than for which they are being used. Sometimes attenuators are also used for stress testing a network link by incrementally reducing the signal strength (increasing the dB attenuation) until the optical link fails, thus determining the signal’s existing safety margin.

Applications

  • Testing equipment

  • Fiber optical CATV

  • Fiber optical sensor

  • Fiber optical telecommunication system


Features

  • Fixed Attenuator(Fixed Type FC, SC, ST, LC)

  • Female to male type ( FC, SC, ST, LC)

  • In-Line Attenuator(Fused and Fiber Jumpers Type)

  • High Return Loss(In-Line and High RL Type)

  • Exact and Stable Attenuation(Variable Type)

Parameters

Item Parameter
Model Fixed, Female&Male, In-line, Variable
Operating Wavelength SM:1310/1550nm SM:1310/1550nm
Attenuation Range 1~30dB
Return Loss APC: ≥60db UPC: ≥55dB PC:≥50dB
Attenuation Tolerance ≤+/-0.5(1-10dB) or ≤+/-1.0(11-30dB)
Maximum Optical Input Power 1000mW
Polarization Dependent Loss ≤0.1dB
Operation Temperature -40°C~+60°C
Storage Temperature -45°C~+ 85°C
Humidity 95%RH

Product tags

fiber optic attenuator 5db

,

optical fiber 5db attenuator

,

10db fiber optic attenuator
