High Bright 2000 nits Outdoor 21.5 Digital Signage, Outdoor PCAP Touch Screen
High Bright 2000 nits Outdoor 21.5 Digital Signage, Outdoor PCAP Touch Screen
Specifications
Brand Name :
Maxbright
Model Number :
M215EDCP-i
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1
Payment Terms :
T/T, Western Union
Supply Ability :
100 sets / month
Delivery Time :
4~5 weeks
Packaging Details :
Pearl cotton shock absorption + carton + pallet packaging
Price :
Negotiable
Panel :
a-Si Active Matrix TFT-LCD
Resolution :
1920 x 1080,
Brightness :
2000 nits
Power Consumption :
120W
Operating voltage :
100 - 240 VAC 50/60Hz
Operating temperature :
-20C -- 50C
Description

Maxbright 21.5" High Bright Outdoor LCD E-poster Model:M215EDCP-i

LED array backlight enhanced

Model : M215EDCP-i

FEATURES:

Active Matrix TFT-LCD Display

High Brightness 2000 nits, Sunlight Viewable

1920 x 1080 Max. Resolution

Aspect Ratio: 9:16 in Portrait mode enabled

Wide Viewing Angles 178 deg. (L/R/U/D)

Wide operating temp range, -20 ～ 50o C

Media player or mini-PC for content playback

Waterproof IP54 enclosure option

PANEL TYPE a-Si active matrix TFT-LCD
ACTIVE AREA 268.11 x 476.64 mm portrait orientation
NATIVE RESOLUTION 1080 x 1920 RGB, 4K model available
PIXEL PITCH 0.24825(H) x 0.24825(V) mm
COLOR 16.7 Million, 8 bits
HORIZONTAL FREQ. 57.3KHz ~ 70KHz
VERTICAL FREQ. 47Hz ~ 63Hz(DVB/PAL), 57Hz ~ 63Hz(NTSC)
BRIGHTNESS 2000 cd/m2, LED Backlight Enhanced
CONTRAST RATIO 1100:1, Dynamic contrast ratio: 9000:1
DIMMING Auto-dimming by Light Sensor
VIEWING ANGLE 89/89/89/89
RESPONSE TIME 3.8/1.2 msec typical
INTERFACE VGA, HDMI x 2
MEDIA PLAYER Media Player (RK3288 Android OS ) (option)
REMOTE CONTROL Support for Full OSD Features
OPERATING VOLTAGE AC 100 ~ 240V 50/60Hz
POWER CONSUMPTION 120W for 2000 nits
STANDBY MODE 3 Watt or less
ACCESSORIES AC Power Cord, Remote Controller
HDMI, VGA cable x 1

OPERATING

(option)

 Media Player RK3288 Quad-core Cortex-A17 1.8GHz, 2GB DDR3, 32-64GB SD, 4 x USB ports, 1 x RJ45
1 x HDMI, 2 X RS232, Android OS 5.1
TOUCH 10 Points PCAP Touch with USB Controller

DIMENSION

WEIGHT

720(H) x 400(W) x 120(D)mm

23 Kg approx
Waterproof IP54 Enclosure
COOLING By cooling fans controlled by temperature senser
ENVIRONMENTAL

Operating Temperature -20-45oC,

Wide temp. -30-50oC (option)
Operating Humidity 10%-85%
Storage Temperature -30-60oC
Storage Humidity 5%-90%
WARRANTY One Year
