Specifications
Brand Name :
No Brand
Model Number :
Transparent LED screen
Certification :
CE, CCC, FCC, CB, EMC, RoHs
Place of Origin :
China
MOQ :
1PCS
Payment Terms :
T/T
Supply Ability :
10000above
Delivery Time :
10-15days
Packaging Details :
Customizable cardboard boxes; Customizable flight cases
Panel Type :
LED
Warranty :
2 Year
Viewing Distance :
Customizable
Vertical Pixel :
Customizable
Maintenance :
Front & Rear Service
Refresh Rate :
1920-3840 Hz
Service :
Front Service
Price :
To be discussed
Description
Transparent LED Screen
Product Overview

Advanced transparent LED display technology offering exceptional clarity, versatility, and ease of installation for various professional applications.

Standard Transparent Series Features
  • Slim and lightweight design at only 6.5kg per cabinet for effortless installation
  • High ventilation with 40% transparency rate and low wind resistance
  • Integrated control box enables rapid front/rear maintenance
  • Multiple splicing options including internal/external right-angle, staggered, and curved configurations
  • Touring applications with dedicated driver chip for minimal grayscale loss
  • Adjustable brightness (800-3000 nits) with IP65 protection rating
Product Item 390
Pixel Pitch 3.91-7.81
Cabinet Size 1000×500
Cabinet Resolution 256×64
Cabinet Weight 6.5 kg
Brightness 2500-3000 nits
Refresh Rate ≥3840 Hz
Grey Rate 14 bit
IP Protection IP65/IP54
Maximum Power 416 W
Average Power 139 W
Curve 90°
Hollowing Rate 40%
Modular Series Features
  • Modular design with universal interchangeability between components
  • Full front/rear maintenance improving efficiency by 5x
  • High-precision arc lock design for perfect splicing
  • Anti-collision cabinet and solder pad protection
  • Interlocking 500×1000mm and 500×500mm cabinet options
Product Item 290 390 480
Pixel Pitch 2.91 3.91 4.81
Cabinet Size 500×500×80 500×500×80 / 500×1000×80 500×500×80 / 500×1000×80
Cabinet Resolution 168×168 128×128 / 128×256 104×104 / 104×208
Cabinet Weight 8 kg 13.5 kg 13.5/ 8 kg
Brightness 4500 nits 4500 nits 5000 nits
Refresh Rate ≥3840 Hz ≥3840 Hz ≥3840 Hz
Grey Rate 14 bit 14 bit 14 bit
IP Protection IP65/IP54 IP65/IP54 IP65/IP54
Maximum Power 773 W 626 W 760 W
Average Power 258 W 209 W 253 W
Curve / ±5°,0° ±10°,±5°,0°
Indoor Series Features
  • Ultra-slim 62mm thick cabinet weighing only 6kg
  • Front maintenance design for easy access
  • 0-90° right-angle splicing customization
  • Multi-purpose installation for fixed and rental applications
  • Ultra-thin wall-mounted installation capability
Product Item 191 261 291 391
Pixel Pitch 1.953 2.604 2.97 3.91
Cabinet Size 500×500×62 500×500×62 500×500×62 500×500×62
Cabinet Resolution 256×256 190×192 168×168 128×128
Cabinet Weight 5.8 kg 5.8 kg 5.8 kg 5.8 kg
Brightness 800 nits 800 nits 800 nits 800 nits
Refresh Rate ≥2800 Hz ≥2800 Hz ≥3840 Hz ≥3840 Hz
Grey Rate 14 bit 14 bit 14 bit 14 bit
IP Protection IP40/IP21 IP40/IP21 IP40/IP21 IP40/IP21
Maximum Power 520 W 520 W 520 W 520 W
Average Power 147 W 147 W 147 W 147 W
Curve 0-90° 0-90° 0-90° 0-90°
Outdoor Series Features
  • Lightweight, slim design with long lifespan and excellent heat dissipation
  • Standardized 1 square meter box size for cost-effective installation
  • Die-cast aluminum construction with anti-deformation module kits
  • Full front maintenance with easy power and signal connections
  • Standardized module hole sizes for direct replacement
  • 90° splicing capability with optional beveled box body
  • Outdoor bare installation without requiring air conditioning
Product Item 480 780 100
Pixel Pitch 4.81 7.81 10.41
Cabinet Size 1000×1000×100 1000×1000×100 1000×1000×100
Cabinet Resolution 208×208 128×128 96×96
Cabinet Weight 30 kg 30 kg 30 kg
Brightness 4500 nits 6500 nits 7000 nits
Refresh Rate 1920 Hz 1920 Hz 1920 Hz
Grey Rate 14 bit 14 bit 14 bit
IP Protection IP65/IP54 IP65/IP54 IP65/IP54
Maximum Power 720 W 680 W 570 W
Average Power 240 W 226 W 190 W
Premium Small-Pitch Series Features
  • Ultra-slim 49mm die-cast cabinet with 16:9 aspect ratio
  • Convenient wall-mounting with complete front/rear maintenance
  • High-definition seamless display technology
  • High gray scale and refresh rate for stable, flicker-free images
  • Hidden cable management with internal high-density connectors
  • Dual backup design for signal and power reliability
Product Item 091 121 151 181 251
Pixel Pitch 0.9 1.25 1.5625 1.875 2.5
Cabinet Size 600×337.5×49 600×337.5×49 600×337.5×49 600×337.5×49 600×337.5×49
Cabinet Resolution 640×360 480×270 384×216 320×180 240×135
Cabinet Weight 4.9 kg 4.9 kg 4.9 kg 4.9 kg 4.9 kg
Brightness 600 nits 600 nits 600 nits 600 nits 600 nits
Refresh Rate ≥3840 Hz ≥3840 Hz ≥3840 Hz ≥3840 Hz ≥3840 Hz
Grey Rate 13 bit 13 bit 13 bit 13 bit 13 bit
IP Protection IP40/IP21 IP40/IP21 IP40/IP21 IP40/IP21 IP40/IP21
Maximum Power 780 W 780 W 690 W 750 W 730 W
Average Power 260 W 260 W 231 W 250 W 244 W
Real-World Applications
