Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm
Specifications
Brand Name :
Kingvisionled
Model Number :
P10
Certification :
CCC / CE / ROHS / UL /ISO9001
Place of Origin :
China
MOQ :
Min 6 Square meter
Price :
USD 550-600 /SQM
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000 Square Meter/Square Meters per Week
Delivery Time :
15 working days
Packaging Details :
Plywood case or flight case
Viewing Angle :
H:160° , V:120°
Module size :
320x160mm
Brightness Control :
256 level
Usage :
Outdoor , subway station, highway station advertising, train station
Led lamp :
SMD3535
Type :
Outdoor led screen
Description

Outdoor LED Screen WIFI 3G 4G Wall Mounted Fixed Installation Outdoor Billboard

Outdoor LED Screen Product Feature:

1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 . Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
9 . Life time >11 years;

Parameters

P6.67

P8

P10

Pixel Configuration

SMD2727

SMD3535

SMD3535

Pixel Pitch(mm)

6.67

8

10

Pixel Density(dots /m²)

22500

15625

10000

Module Size(L x W x H)/(mm)

480x320

480x320

480x320

Panel Size(L x W x H)/( mm)

960x960x105

960x960x105

960x960x105

Panel Material

Iron

Iron

 Iron

Panel Weight(kg/m2)

45

45

45

Color Depth(Bit)

16

16

16

Gray Level

65536

65536

65536

Refresh Rate(Hz)

3840

3840

3840

Driver Method

1/5

1/3

1/2

Brightness

6000-10,000

6000-10,000

6000-10,000

Viewing Angle(H/V°)

140/140

140/140

140/140

AC Power Input(V)

AC220±10%

AC220±10%

AC220±10%

AC Power Frequency(Hz)

50/60

50/60

50/60

Max. AC Power Input (W/m²)

550

550

550

Avg. AC Power Input (W/m²)

170

170

170

Storage Temperature

-40~60

-40~60

-40~60

Working Temperature

-20~50

-20~50

-20~50

Storage Humidity

10%~60%RH

10%~60%RH

10%~60%RH

Working Humidity

10%~60%RH

10%~60%RH

10%~60%RH

IP Rating

IP66

IP66

IP66

Life Span(hours)

100000

100000

100000

Installation & Maintenance

Front&Rear

Front&Rear

Front&Rear

Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm

Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm

Smd3535 Wall Mounted Outdoor Fixed Led Display 4G WIFI 3G Building 320x160mm

Outdoor LED Screen FAQ

Q1:What’s the function?

A1:Support various formats,like VGA,Video,AVI,DAT,etc.

Q2:How to install and install way.

A2:No need steel structure for installation to save a lot of cost,Have professional connector,Quick lock assembly 1 hour for 90 sqm installation

Q3:LED display modules are generally expressed in PX,such as P2 P3 P4...P8 P10,what does this mean?

A3:P3 P4...P8 P10 means that the pixel pitch is 3mm 4mm...10mm,which determines resolution of a display.Pixel pitch smaller,led resolution higher.

Q4:What pixel pitch should I choose on my display?

A4:It’s mainly depends on the viewing distance,the size of the display screen,the desired effect the application scenario and the customer budget.
