P5 Waterproof Full Color Outdoor LED Advertising Display 64x32 Pixel 320x160mm Panel
P5 Waterproof Full Color Outdoor LED Advertising Display 64x32 Pixel 320x160mm Panel
Specifications
Brand Name :
ABT
Model Number :
P5
Certification :
FCC,CE,UL,ROSH,ISO9001
Place of Origin :
Shenzhen,China
MOQ :
1square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1500square meter/month
Delivery Time :
7-15days
Packaging Details :
wooden case;flight case
Module size :
320*160mm
Driving mode :
constant driving 1/8
Led type :
SMD2727
Brightness :
7000cd/sqm
Tube chip color :
full color
name :
outdoor full color LED display
Description

P5 outdoor waterproof full color led display 64x32 pixel 320x160mm panel

Product Features:

1. The flatness is good and the picture is uniform and pleasing to the eye.
2. High grayscale and high refresh, the studio video effect is realistic.
3. Safety performance structure, enhanced design is not easy to deform.
4. Large-angle imaging display technology to meet the wide range Angle to view unbiased color.
5. It can be designed and maintained on the front and back, easy and fast and easy to maintain.

Applications: Widely used for advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places etc.

Technical Parameters:

Pitch size

5 mm

Pixel configuration

1 Red, 1 Green ,1 Blue, SMD 3-in-1

Cabinet solution(W*H)

192 dots * 192 dots

Pixel density

40000 dots/sqm

Cabinet size(W*H)

960 mm*960mm

Brightness(average)

≥6000 cd/ sqm

View angle(H/V)

H/V 140/120 degree

Power consumption

100 W/sqm ~ 1200 W/sqm

Net weight

50 kg/sqm

Voltage

220V/110V±15% 50 Hz

Color scale

256~65536 degree /1.07 billion colors

Display mode

VGA 640X480—VGA 1600X1024

Life span

≥100,000 hours

Refresh frame frequency

≥360 HZ

Exchange frame speed

>150 frames per second

Control distance

≤100M (Cat.5 without repeater) /500 M (multi-mode optical fiber)/20000m(single-mode optical fiber)

Operating temperature

-25°C~+60°C

Operating humidity

10%—95% RH

Software

LED studio

Best view distance

>5m

Communication port

VGA

Control mode

Synchronous, real time with PC

Drive mode

Constant current driving

Protection of power supply

Overtemperature, overcurrent, overvoltage etc.

Operating system

Windows 98/Me/2000/Xp

Brightness adjustment

100 levels automatically or by hand

Drive mode

1/8 scan, constant current

P5 Waterproof Full Color Outdoor LED Advertising Display 64x32 Pixel 320x160mm Panel


Our Service

1. Pre-sales service :
Our team design and make solutions based on different requirements from different customers, what you think is what we can do.

2. After-sales services:
1). We provide customer service through Skype, phone or email, supply you video or drawing to solve problems.
2). We provide remote control service through internet to achieve real time service, which will short time of solving problems.
3). We provide professional engineer one-to-one to keep fastly reply.

3. Installation Service:
1). We provide detailed CAD drawing to customer for preparing metal structure.
2). We could dispatch our engineer to your place , guide installation and free training.
3). Special designs have special solutions; we will make perfect solutions to satisfy all customers' requirements.
