Specifications
Model Number :
Q3G
Lifespan (Hours) :
70000
Input voltage :
DC24V
Functions :
Machine Tool Warning Light
Brand Name :
OUJVAN
Lighting solutions service :
Lighting And Circuitry Design
MOQ :
2 pieces
Lamp Body Material :
ABS
Lamp Luminous Flux(lm) :
400
Protection grade :
IP50
Price :
$8/piece-$13/piece
Emitting Color :
Red, Yellow, Green
Input Voltage(V) :
DC24V DC12V optional
Length of the wire :
0.5m
Glow color :
red,yellow,green
Product Weight（kg） :
0.2
Shiny number :
60-70/min
Color Temperature(CCT) :
RYG
Color Rendering Index(Ra) :
80
Lamp Luminous Efficiency(lm/w) :
80
MOQ :
2 Pcs
IP Rating :
IP50
Beam Angle(°) :
360
Certification :
CE
Buzzer :
>90dB
Type :
Equipment Indicator Lights
Application :
CNC Machine Signal Tower Lighting
Place of Origin :
Guangdong, China
Support Dimmer :
No
Light Source :
LED
Warranty(Year) :
3-Year
Product name :
Led Tri-Color Warning Signal Indicator Tower Light Buzzer
Description
Wholesale Sailing Appearance Led Tri-Color Warning Signal Indicator Tower Light Buzzer
Product name Wholesale Sailing Appearance Led Tri-Color Warning Signal Indicator Tower Light Buzzer
Model number Q3G
Input voltage DC24V
Input current

Monochromatic:50mA

Buzzer:15mA
Power 1.2W-2W
Protection grade IP50
Length of the wire 0.5m
Light body color Silver
Light source Patch 2835 LED
Light life 70000 hours
Surface temperature <50℃
Buzzer >90dB
Shiny number 60-70/min
Material

lampshade:PC

Lamp shell:ABS
Light Angle 360°
Glow color red,yellow,green
Certification CE, RoHS
Environment temperature -20~45℃
Storage temperature -40~70℃
Environmental humidity 10~90%
Store humidity 10~90%
MOQ 2 Pcs
Lead time within 1-3 working days
Payment Paypal/WU/TT/Trade Assurance/Money Gram/Cash
Shipping DHL/UPS/FedEx/Aramex/EMS/HK Post

LED Q3G Sailboat Tri-Color Warning Light: Utility Model Patented Industrial Signaling with Unique Aesthetics

Product Overview

The LED Q3G is a utility model patented (ZL 2019 3 0380345.X) sailboat-shaped tri-color warning light, featuring a unique appearance and high brightness for clear color differentiation. It is constructed with bulletproof glue and PC material, along with a foldable design, ensuring durability and ease of transportation.

Light Source & Performance

It adopts Taiwan crystal 2835 lamp beads, providing a stable, bright, and uniform light source. The technical specifications include:

  • Current: 100mA per color, 15mA for the buzzer.
  • Flash frequency: 60-70 Hz/min.
  • Buzzer volume: >95dB.
  • IP Rating: IP50 (with buzzer).
  • Temperature resistance: <60°C.
  • Lifespan: 50,000 hours.
  • Installation: Fixed by screw.
  • Material: PC body and PC lens.
Coding Principle

The LED Q3G has a structured coding system for customization:

  • Model No: Q3G
  • Layer: 1 (one-layer)
  • Mounting: Foldable type (A)
  • Voltage: DC24V (02)
  • Function: Steady (B) or Steady with buzzer (F)
  • Connect Type: PNP&NPN (T)
  • Color: Red (R), Yellow (Y), Green (G)
Applications & Features
Applications

Suitable for automated assembly lines, automation equipment, security equipment, LED encapsulation equipment, alarm systems, SMT equipment, CNC machine tools, mechanical engraving machines, lathes, milling machines, and mining machinery.

Features
  1. Easy Installation & Transport: Foldable design allows for easy installation and convenient transfer.
  2. Dual Patent & Durable Build: Adopts PC and bulletproof glue, being a double patented product.
  3. Audible Alerts: Equipped with a >95dB buzzer for effective warning.
  4. Custom Branding: Supports customizable engraved illuminated LOGO to showcase the brand.

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp


Factory Supply Patented Q3G Sailboat Tri-Color LED Warning Light DC24V Foldable Signal Lamp

FAQ:
Q:How to order our product ?

1).Please tell us the model and quantity and other request you need.

2).We make the PI for you.

3).After you confirm the PI, we arrange the order for you after receiving your payment.

4).After the goods finished, we send the goods out to you and tell you the tracking number.

5).We will track your goods until you receive the goods.

Q: What's your warranty ?

A: One years

Q: What's your shipment method?

A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.

Q: What's about MOQ?

A: First order MOQ=2pcs

Q: If i want to release order, what's the payment method you accept ?

A: We accept T/T, Paypal, Western union, L/C.

Q: If i want to release order, what's the process?

A: Thanks. You can send inquiry to us by email, we will reply within 24hrs.
