Specifications
IP Rating :
IP50
Beam Angle(°) :
360
Lamp body color :
silvery / black
Brand Name :
OUJVAN
Product Weight（kg） :
0.8
Product name :
Q11 Signal indicator light
Input voltage :
DC24V
Model Number :
Q11
Lifespan (Hours) :
70000
Protection grade :
IP50
Input Voltage(V) :
DC24V DC12V AC220V optional
Buzzer :
>90dB
MOQ :
2 pieces
Lamp Body Material :
PMMA
Lamp Luminous Flux(lm) :
400
Length of the wire :
0.5m
Color Temperature(CCT) :
RYG
Color Rendering Index(Ra) :
80
Lamp Luminous Efficiency(lm/w) :
80
Application :
CNC Machine Signal Tower Lighting
Price :
$8/piece-$13/piece
Emitting Color :
Red, Yellow, Green
Support Dimmer :
No
Glow color :
red,yellow,green
Certification :
CE
Shiny number :
60-70/min
Place of Origin :
Guangdong, China
Type :
Equipment Indicator Lights
Light Source :
LED
Warranty(Year) :
3-Year
Functions :
Industrial Warning Light
Description
OUJVAN Q11 LED Signal Indicator Light DC24V IP54 PNP NPN Industrial Tower Warning Lamp

The LED Q11 Signal Indicator Light is a cutting-edge industrial signaling solution designed for efficient operational status communication. It features a unique square design with high-transparent crystal full frosted luminescence, offering an innovative appearance while delivering comprehensive functions and excellent cost performance.

Key Advantages
  • Optical Excellence: Utilizes bright LED patch technology, ensuring high brightness, large illumination angle, low thermal resistance, color concentration, ultra-low light decay process, and exceptionally long lifespan
  • Reliable Circuit Design: Incorporates wide margin circuit and high-quality components, providing comprehensive protection for the overall lifespan of the lamp
  • Safe & Efficient Electronics: Internal electronic components are arranged rationally, guaranteeing safe and efficient operation
Performance Specifications
  • Current: 60mA per color, 15mA for buzzer
  • Flash Frequency: 60-70 Hz/min
  • Buzzer Volume: >95dB
  • IP Rating: IP54 (dust and water-splash resistant)
  • Temperature Resistance: <60°C
  • Lifespan: 50,000 hours
  • Installation: Fixed by screw
  • Material: ABS body for durability
  • Voltage & Compatibility: Operates on DC24V, compatible with both PNP and NPN connections
Customization & Coding Principle

The LED Q11 offers customization in color (red, yellow, green) and function (steady light or steady light with buzzer).

Model Structure:
Q11 - [Layer] - [Mounting] - [Voltage] - [Function] - [Connect Type] - [Color]

Available Options:
• Layer: 1 (one-layer)
• Mounting: Foldable type (A)
• Voltage: DC24V (02)
• Function: Steady (B) or Steady with buzzer (F)
• Connect Type: PNP&NPN (T)
• Color: Red (R), Yellow (G), Green (Y)
Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer
Technical Specifications
Product name Q11 Signal indicator light
Input voltage DC24V
Protection grade IP50
Length of the wire 0.5m
Buzzer >90dB
Shiny number 60-70/min
Glow color red, yellow, green
Lamp body color silvery
Operation Life 70,000 hours
Power 1.2W～2W
Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer Industrial Q11 LED Signal Tower Light with 70000 Hours Lifespan IP54 Protection and >95dB Buzzer
